GREE GMV5E DC INVERTER VRF UNITS SERVICE MANUAL
11
Model
GMV-2295WM/E-
X
GMV-2350WM/E-
X
GMV-2405WM/E-
X
GMV-2460WM/E-
X
Refrigeration Capacity
HP
82
84
86
88
Combination Mode
—
GMV-450WM/E-X
+GMV-615WM/E-X
+GMV-615WM/E-X
+GMV-615WM/E-X
GMV-504WM/E-X
+GMV-615WM/E-X
+GMV-615WM/E-X
+ GMV-615WM/E-X
GMV-560WM/E-X
+GMV-615WM/E-X
+GMV-615WM/E-X
+GMV-615WM/E-X
GMV-615WM/E-X
+GMV-615WM/E-X
+GMV-615WM/E-X
+GMV-615WM/E-X
Power Supply
380-415V 3N~ 50Hz/60Hz
Rated
Capacity
Cooling
Nom.
kW
229.5
234.9
240.5
246
Heating
Nom
kW
234.5
234.9
240.5
246
Max
kW
257
263.5
270
276
Dimensions
(W x D x H)
mm
1340×765×1740
+1340×765×1740
+1340×765×1740
+1340×765×1740
1340×765×1740
+1340×765×1740
+1340×765×1740
+1340×765×1740
1340×765×1740
+1340×765×1740
+1340×765×1740
+1340×765×1740
1340×765×1740
+1340×765×1740
+1340×765×1740
+1340×765×1740
Tubing
Dimensions
Liquid Pipe
mm
Φ22.2
Φ22.2
Φ22.2
Φ22.2
Gas Pipe
mm
Φ44.5
Φ44.5
Φ44.5
Φ44.5
Balance pipe
mm
Φ9.52
Φ9.52
Φ9.52
Φ9.52
Weight
kg
360+385+385
+385
360+385+385
+385
385+385+385
+385
385+385+385
+385
Refrigerant
Name
-
R410A
R410A
R410A
R410A
Built-in Filling
Volume
kg
10.3+14.3
+14.3+14.3
11.3+14.3
+14.3+14.3
14.3+14.3
+14.3+14.3
14.3+14.3
+14.3+14.3
Note：
① Due to the same capacity, GMV-280WM/E1-X model and GMV-280WM/E-X model can replace
each other for operation, GMV-450WM/E1-X model and GMV-450WM/E-X model can replace
each other for operation.
② A combination model is not allowed to be combined with the outdoor units belonging to different
series.
1.5 Electrical Parameters
1.5.1 Power Cable Wire Gauge and Circuit Breaker Selection
Model
Basic models
Circuit
breaker
capacity
(A)
Circuit breaker
capacity for
combined units
(A )
Wire size of
power supply
(mm
2
)
Wire size of combined unit
(mm
2
)
GMV-224WM/E-X
-
20
20
2.5
2.5×5
GMV-280WM/E1-X
-
25
25
2.5
2.5×5
GMV-280WM/E-X
-
25
25
2.5
2.5×5
GMV-335WM/E-X
-
32
32
4.0
4.0×5
GMV-400WM/E-X
-
40
40
6.0
6.0×5
GMV-450WM/E1-X
-
40
40
6.0
6.0×5
GMV-450WM/E-X
-
40
40
6.0
6.0×5
GMV-504WM/E-X
-
50
50
10
10×5
GMV-560WM/E-X
-
63
63
10
10×5
GMV-615WM/E-X
-
63
63
10
10×5
GMV-680WM/E-X
280+400
63
25+40
2.5+6.0
2.5×5+6.0×5
GMV-730WM/E-X
280+450
63
25+40
2.5+6.0
2.5×5+6.0×5
GMV-785WM/E-X
280+504
80
25+50
2.5+10
2.5×5+10×5
GMV-850WM/E-X
280+560
80
25+63
2.5+10
2.5×5+10×5
