The installation site – outdoor unit
1. Choose the installation location in a way that noise from the system or out-
going air from the system neither jeopardises nor bothers neighbours, ani-
mals or vegetation.
2. Make sure to choose an installation location which has free airflow
(sufficient air volume) and is dry. Avoid direct sunlight or locations which
are subject to strong winds.
3. Make sure that walls can stand the weight of the unit and can handle the
associated vibration.
4. Consider the dimensions diagram (see page 58) during installation in or-
der to achieve good accessibility for maintenance and services and to re-
duce the risk for material assets.
5. Mount the unit out of the reach of children.
6. Make sure that walkways are not blocked and that there are no negative
influences to the skyline.
7. In case of any doubts refer to the responsible authority in the country
where the installation is done.
8. In some countries special laws and restrictions for the mounting of split air
conditioning units may apply.
The installation site – indoor unit
Choose an installation site according to the dimensions (see page 58) diagram.
1. Make sure that condensate can flow out easily.
2. Keep in mind that the pre-installed pipe-set is exactly 5 m and no modifi-
cations are permitted (to shorten or to lengthen the refrigerant tubes) and
that connections to the outdoor unit are easy to be set up.
3. Easy access to the indoor unit must be ensured for maintenance and ser-
vicing purposes such as a change of the filters.
4. The indoor unit should be mounted out of the reach of children.
5. Make sure that the installation position of the indoor unit can handle the
weight of the unit and the associated vibration. At best no additional noise
pollution should be generated.
6. Keep the unit away from heat sources, flammable and explosive materials.
7. The air inlet and outlet vent should not be obstructed, make sure that the
air can be blown throughout the entire room.
8. There shall be no electric appliance, power switch or socket under the in-
door unit.
9. There should be a minimum distance of about 1 m from TV-sets or any
other electric appliances.
Modification of
refrigerant trans-
fer pipes is not
permitted!
