Super Free Match
Service Manual
PRODUCT
10
Cozy
Model
GWH09MB-D3
DNA3D/I
GWH12MB-D3
DNA3D/I
GWH18MC-D3
DNA3D/I
GWH24MD-D3
DNA3D/I
Capacity
Cooling kW 2.6 3.5 5.3 6.3
Heating kW 2.87 3.8 5.8 6.75
Power supply V-Ph-Hz 208/230-1-60 208/230-1-60 208/230-1-60 208/230-1-60
Motor power input kW 0.05 0.05 0.05 0.10
Air flow volume
m
3
/h 520 570 850 1000
CFM 306 335 500 588
Sound pressure level
(SH/H/M/L)
dB(A) 41/37/35/26/- 42/38/36/28/- 46/44/40/35/- 53/45/41/37/-
Fan motor
Output kW 0.02 0.02 0.02 0.06
Running
current
A 0.20 0.20 0.32 0.41
Connecting
pipe
Gas inch 3/8″(Φ9.52mm) 3/8″(Φ9.52mm) 1/2″(Φ12.7mm) 5/8″(Φ15.9mm)
Liquid inch 1/4″(Φ6.35mm) 1/4″(Φ6.35mm) 1/4″(Φ6.35mm) 1/4″(Φ6.35mm)
Connection method Flare Connection Flare Connection Flare Connection Flare Connection
Drain pipe
External
dia.
mm Φ20 Φ20 Φ20 Φ20
Thickness mm 1.5 1.5 1.5 1.5
Outline
dimension
W×D×H mm 845×180×275 845×180×275 940×200×298 1007×219×315
Package
dimension
W×D×H mm 918×258×370 918×258×370 1013×288×395 1076×328×398
Net Weight/ Gross weight kg 10/13 10/13 13/17 16/21
Loading quantity
20'GP 336 336 254 210
40' GP 684 684 541 427
40' HQ 798 798 609 488
Notes:
a. Refer to the product nameplate for parameters and specification of the unit;
b. The data will change with the change of products. Refer to those parameters listed on nameplate.
c. Noise was tested in semi-silenced room, so the actual noise value will be a little higher for change of ambient.
