Super Free Match
Service Manual
PRODUCT
11
4.2.2 Duct type
Model Heat pump
GFH(09)EA-D3D
NA1A/I
GFH(12)EA-D3D
NA1A/I
GFH(18)EA-D3D
NA1A/I
Capacity
Cooling KW 2.5 3.50 4.5
Heating KW 2.8 3.85 5.5
Power supply V-Ph-Hz 208/230-1-60 208/230-1-60 208/230-1-60
Motor power input kW 0.08 0.08 0.10
Air flow volume
m3/h 450 500 700
CFM 265 294 412
Sound pressure level (H/M/L) dB(A) 37/34/31 39/35/32 41/37/33
Fan motor
Output kW 0.04 0.049 0.075
Running current A 0.35 0.35 0.43
Connecting pipe
Gas inch 3/8″(Φ9.52mm) 3/8″(Φ9.52mm) 1/2″(Φ12.7mm)
Liquid inch 1/4″(Φ6.35mm) 1/4″(Φ6.35mm) 1/4″(Φ6.35mm)
Connection method Flare Connection Flare Connection Flare Connection
Drain pipe
External dia. mm Φ31 Φ31 Φ31
Thickness mm 3 3 3
Outline dimension W×D×H mm 700×615×200 700×615×200 900×615×200
Package dimension W×D×H mm 893×743×305 893×743×305 1123×743×305
Net Weight/ Gross weight kg 22/27 23/29 27/36
Loading quantity
20'GP 108 108 90
40' GP 234 234 180
40' HQ 234 234 180
