Super Free Match
Service Manual
PRODUCT
12
Model Heat pump GFH(21)EA-D3DNA1A/I GFH(24)EA-D3DNA1A/I
Capacity
Cooling KW 6.0 7.0
Heating KW 6.6 8.0
Power supply V-Ph-Hz 208/230-1-60 208/230-1-60
Motor power input kW 0.124 0.124
Air flow volume
m3/h 1000 1000
CFM 588.5 588.5
Sound pressure level(H/M/L) dB(A) 42/38/34 42/38/34
Fan motor
Output kW 0.061 0.061
Running current A 0.54 0.54
Connecting pipe
Gas inch 5/8″(Φ15.9mm) 5/8″(Φ15.9mm)
Liquid inch 3/8″(Φ9.52mm) 3/8″(Φ9.52mm)
Connection method Flare Connection Flare Connection
Drain pipe
External dia. mm Φ31 Φ31
Thickness mm 3 3
Outline dimension W×D×H mm 1100×615×200 1100×615×200
Package dimension W×D×H mm 1323×743×305 1323×743×305
Net Weight/ Gross weight kg 31/41 31/41
Loading quantity
20'GP 72 72
40' GP 162 162
40' HQ 162 162
Notes:
a. Refer to the product nameplate for parameters and specification of the unit;
b. The data will change with the change of products. Refer to those parameters listed on nameplate.
c. Noise was tested in semi-silenced room, so the actual noise value will be a little higher for change of ambient.
