4.2.3 Cassette type
Model Heat pump
GKH(12)BA-D3
DNA2A/I
GKH(18)BA-D3
DNA2A/I
GKH(24)BA-D3
DNA1A/I
Capacity
Cooling KW 3.5 4.5 6.7
Heating KW 4.0 5.0 8.0
Power supply V-Ph-Hz 208/230-1-60 208/230-1-60 208/230-1-60
Motor power input kW 0.05 0.05 0.10
Air flow volume
m3/h 600 600 1180
CFM 353 353 694
Sound pressure level (H/M/L) dB(A) 46/44/42 46/44/42 39/37/35
Fan motor
Output kW 0.011 0.011 0.05
Running current A 0.23 0.23 0.43
Connecting
pipe
Gas inch 3/8″(Φ9.52mm) 1/2″(Φ12.7mm) 5/8″(Φ15.9mm)
Liquid inch 1/4″(Φ6.35mm) 1/4″(Φ6.35mm) 3/8″(Φ9.52mm)
Connection method Flare Connection Flare Connection Flare Connection
Drain pipe
External dia. mm Φ31 Φ31 Φ31
Thickness mm 3 3 3
Outline
dimension
Body
W×D×H
mm 570×570×230 570×570×230 840×840×240
Panel
W×D×H
mm 650×650×50 650×650×50 950×950×60
Package
dimension
Body
W×D×H
mm 851×731×325 851×731×325 963×963×325
Panel
W×D×H
mm 733×673×117 733×673×117 1043×1028×130
Body Net Weight/Gross weight kg 18/23 18/23 28/35
Panel Net Weight/Gross weight kg 2.5/3.65 2.5/3.65 6.5/10
Loading quantity
20'GP 102 102 40
40' GP 209 209 108
40' HQ 246 246 128
Notes:
a. Refer to the product nameplate for parameters and specification of the unit;
b. The data will change with the change of products. Refer to those parameters listed on nameplate.
c. Noise was tested in semi-silenced room, so the actual noise value will be a little higher for change of ambient.
