Super Free Match
Service Manual
PRODUCT
14
4.2.4 Floor ceiling type
Model Heat pump
GTH(09)BA-D3
DNA1A/I
GTH(12)BA-D3
DNA1A/I
GTH(18)BA-D3
DNA1A/I
GTH(24)BA-D3
DNA1A/I
Capacity
Cooling KW 2.5 3.5 5.0 6.7
Heating KW 2.8 3.85 5.5 8.0
Power supply V-Ph-Hz 208/230-1-60 208/230-1-60 208/230-1-60 208/230-1-60
Motor power input kW 0.055 0.055 0.11 0.145
Air flow volume
m3/h 650 650 950 1250
CFM 382.5 382.5 559 736
Sound pressure level
(H/M/L)
dB(A) 40/38/36 40/38/36 45/42/40 48/46/44
Fan motor
Output kW 0.015 0.02 0.02 0.04
Running
current
A 0.28 0.28 0.56 0.63
Connecting
pipe
Gas inch 3/8″(Φ9.52mm) 3/8″(Φ9.52mm) 1/2″(Φ12.7mm) 5/8″(Φ15.9mm)
Liquid inch 1/4″(Φ6.35mm) 1/4″(Φ6.35mm) 1/4″(Φ6.35mm) 3/8″(Φ9.52mm)
Connection method Flare Connection Flare Connection Flare Connection Flare Connection
Drain pipe
External
dia.
mm Φ17 Φ17 Φ17 Φ17
Thickness mm 1.75 1.75 1.75 1.75
Outline
dimension
W×D×H mm 1220×700×225 1220×700×225 1220×700×225 1220×700×225
Package
dimension
W×D×H mm 1343×823×315 1343×823×315 1343×823×315 1343×823×315
Net Weight/Gross weight kg 40/50 40/50 40/50 45/54
Loading quantity
20'GP 66 66 66 66
40' GP 132 132 132 132
40' HQ 132 132 132 132
Notes:
a. Refer to the product nameplate for parameters and specification of the unit;
b. The data will change with the change of products. Refer to those parameters listed on nameplate.
c. Noise was tested in semi-silenced room, so the actual noise value will be a little higher for change of ambient.
