Super Free Match
Service Manual
PRODUCT
15
4.2.5 Console type
Model Heat pump
GEH(09)AA-D3DNA1
C/I
GEH(12)AA-D3DNA1
C/I
GEH(18)AA-D3DNA1
C/I
Capacity
Cooling KW 2.6 3.5 5.3
Heating KW 2.8 3.8 5.8
Power supply V-Ph-Hz 208/230-1-60 208/230-1-60 208/230-1-60
Motor power input kW 0.05 0.05 0.05
Air flow volume
m3/h 500 600 650
CFM 294 353 383
Sound pressure level
(SH/H/MH/M/ML/L/SL)
dB(A) 40/38/36/33/30/27/25 42/40/38/37/35/32/27 48/46/44/41/37/35/32
Fan motor
Output kW 0.03 0.03 0.03
Running
current
A 0.14 0.14 0.14
Connecting
pipe
Gas inch 3/8″(Φ9.52mm) 3/8″(Φ9.52mm) 1/2″(Φ12.7mm)
Liquid inch 1/4″(Φ6.35mm) 1/4″(Φ6.35mm) 1/4″(Φ6.35mm)
Connection method Flare Connection Flare Connection Flare Connection
Drain pipe
External
dia.
mm Φ20 Φ20 Φ20
Thickness mm 1.5 1.5 1.5
Outline
dimension
W×D×H mm 700×215×600 700×215×600 700×215×600
Package
dimension
W×D×H mm 791×286×710 791×286×710 791×286×710
Net Weight/Gross weight kg 15/18 15/18 15/18
Loading quantity
20'GP 168 168 168
40' GP 348 348 348
40' HQ 440 440 440
Notes:
a. Refer to the product nameplate for parameters and specification of the unit;
b. The data will change with the change of products. Refer to those parameters listed on nameplate.
c. Noise was tested in semi-silenced room, so the actual noise value will be a little higher for change of ambient.
