Gree SUPER+ MULTI ULTRA Series User Manual

Super Free Match
Service Manual
MAINTENANCE
N
181
7.2.4 Floor ceiling type
GTH(09)BA-D3DNA1A/I; GTH(12)BA-D3DNA1A/I; GTH(18)BA-D3DNA1A/I; GTH(24)BA-D3DNA1A/I
Part list:
GTH(09)BA-D3DNA1A/I for CN610N0060; GTH(12)BA-D3DNA1A/I for CN610N0070;
GTH(18)BA-D3DNA1A/I for CN610N0050; GTH(24)BA-D3DNA1A/I for CN610N0080
NO. Description
GTH(09)BA-D3DNA1A/I
GTH(12)BA-D3DNA1A/I
GTH(18)BA-D3
DNA1A/I
GTH(24)BA-D3
DNA1A/I
Code Qty Code Qty Code Qty
1 Fixed Mount 26909426R 1 26909426R 1 26909426R 1
2 Louver Clamp 26112127 2 26112127 2 26112127 2
3 Guide Louver 10619403 1 10619403 1 10619403 2
4 Rotating Shaft 26909430 4 26909430 4 26909430 4
