Super Free Match
Service Manual
MAINTENANCE
184
5 Temp. Sensor sleeving 05212423 1 05212423 1 05212423
1
6 Rear Case assy 22202462 1 22202462 1 22202462
1
7 Centrifugal fan 10312005 1 10312005 1 10312005
1
8 Fan Motor 15012123 1 15012123 1 15012123
1
9 Step Motor 1521210805 1 1521210805 1 1521210805
1
10 Crank 73012005 1 73012005 1 73012005
1
11 Swing Assy 10102042 1 10102042 1 10102042
1
12 Terminal Board 42011233 1 42011233 1 42011233
1
13 Switch Board 30112007 1 30112007 1 30112007
1
14 Display Board 30568131 1 30568131 1 30568131
1
15 Fuse 46010055 1 46010055 1 46010055
1
16 Radiator 49010252 1 49010252 1 49010252
1
17 Signal Wire 4003004202 1 4003004202 1 4003004202
1
18 Jumper 4202300101 1 4202300102 1 4202300103
1
19 Main Board 30138613 1 30138613 1 30138613
1
20 Electric Box 20112116 1 20112116 1 20112116
1
21 Electric Box Assy 2020262201 1 2020262101 1 2020242301
1
22 Air Louver (upper) 10512143 2 10512143 2 10512143
2
23 Swing lever 10582096 2 10582096 2 10582096
2
24 Shaft of guide louver 10542020 2 10542020 2 10542020
2
25 Water Tray Assy 20182141 1 20182141 1 20182141
1
26 Air Louver (lower) 10512144 2 10512144 2 10512144
2
27 Axis (lower step motor) 10542034 1 10542034 1 10542034
1
28 Step Motor 1521210101 1 1521210101 1 1521210101
1
29 Connecting Cable 400204056 0 400204056 0 400204056
0
30 Tube Sensor 390000591 1 390000591 1 390000591
1
31
Pipe Connection Nut
accessories
06320020 1 06320020 1 06320020
1
32
Ambient Temperature
Sensor
3900004508 1 3900004508 1 3900004508
1
