Super Free Match
Service Manual
CONTROL
47
Press this button can turn on or turn off the air conditioner. After turning on the unit, operation indicator
"
" on indoor unit is ON (green indicator. Color may be different for different models) and indoor unit gives out
a sound.
2) MODE
Press this button, Auto, Cool, Dry, Fan, Heat mode can be selected circularly.
After energization, AUTO mode is defaulted. In AUTO mode, the set temperature will not be displayed on the
LCD, and the unit will automatically select the suitable operation mode in accordance with the room temp erature
to make indoor room comfortable.
3) “＋”
Press this button to increase set temperature. Hold it down for above 2 seconds to rapidly increase set
temperature. In AUTO mode, set temperature is not adjustable.
4) “－”
Press this button to decrease set temperature. Hold it down for above 2 seconds to rapidly decrease set
temperature. In AUTO mode, set temperature is not adjustable.
5) FAN
Press this button, Auto, Low, Medium, High speed can be circularly selected.
Low speed Medium speed High speed
6) SWING UP and DOWN
Press this button
to set up &down swing angle, which circularly changes as below:
This remote controller is universal. If any command
or
is sent out, the unit will carry out the
command as
.
indicates the guide louver swings as:
7) TIMER ON
Press this button to initiate the auto-ON timer. To cancel the auto-timer program, simply press this button
again.
After pressing this button,
disappears and "ON" blinks. 00:00 is displayed for ON time setting. Within
5 seconds, press ＋ or － button to adjust the time value. Every press of either button changes the time setting
To Next Page
