GREER Company Insight Calibration And Troubleshooting Manual

7
W450311 Rev C 2/13
2.3.1 Group “A” Fault Codes
Group “A” fault codes represent faults detected for analog sensors.
NOTE: Check and repair “B” and “C” group faults before investigating group “A” faults.
The following chart details all the available codes in the left column and the actions to take in the right
column.
FAULT
CODE
SWING
SENSOR
BOOM
ANGLE
SENSOR
EXTENSION
SENSOR
TDX 1
ROD
PRESSURE
TDX 0
PISTON
PRESSURE
ACTION
000
No Fault Found
None
001
X
Refer to Replacing the
Computer
002
X
003
X
X
004
X
Refer to Calibrating the
Extension Sensor Zero,
Calibrating Span of Extension
and Angle, and Reeling Drum
Voltage Checks.
008
X
Refer to Calibrating the Angle
Sensor Zero, Calibrating Span
of Extension and Angle, and
Reeling Drum Voltage
Checks.
012
X X
Refer to Calibrating the Angle
Sensor Zero, Calibrating the
Extension Sensor Zero,
Calibrating Span of Extension
and Angle, and Reeling Drum
Voltage Checks.
016
X
Refer to Calibrating the Swing
Potentiometer, and Reeling
Drum Voltage Checks.
2.3.2 Group “B” Fault Codes
Group “B” fault codes represent faults detected for internal analog functions and power feeds to the
function kickout and anti-two block switches.
FAULT
CODE
FKO
POWER
FEED
A2B
POWER
FEED
DISPLAY
CONSOLE
ADC 2
INTERNAL
FAULT
ADC 1
INTERNAL
FAULT
ACTION
000
No Fault Found
008 X
Refer to sections 6.5 and
6.6 for Troubleshooting
Information.
016 X
Check Crane Circuit
Breakers
