Grill'D Aurora - Page 60

60
Door Mini and Short/Long
The firebox door can be
mounted in such ways that it
will open either to the right, or
to the left. To do so, you need to
pull out the metal pin, which is
fixed to the door, and carefully
remove the metal spacer
installed under the door.
Further:
1) Choose the door opening
direction and mount the door
onto the seat. The spacer shall
be installed on the hole under
the door.
2) Fix the door in this position
via the metal pin.
1
2
1
2
1
2
Decorative screen
Note: install the screen only aer installaon of the heater on the place of permanent opera-
on.
Procedure:
1) Match the mounng holes on the screen and on the heang ue frame;
2) Fix the screen with the self-tapping screws (included into the contents of delivery).
Door mini Door Short/Long
