Grizzly G0454 User Manual

-50-
G0453/G0454 (Mfg. Since 3/08)
G0453 Headstock Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0453001 COGGED V-BELT MX-60 58 P0453058 FLANGE BOLT M6-1 X 10
2 P0453002 OIL FILL LABEL 59 P0453059 TOP COVER
3 P0453003 CHAIN 06B-1 X 49 31LINKS 60 P0453060 FLAT HD SCR M6-1 X 8
4 P0453004 CHAIN 06B-1 X 63 24LINKS 61 P0453061 CUT LIMIT PLATE
5 P0453005 FLAT WASHER 6MM 62 P0453062 SET SCREW M8-1.25 X 16
6 P0453006 CAP SCREW M6-1 X 12 63 P0453063 E-CLIP 15MM
7V2 P0453007V2 MAGNETIC SWITCH ASSEMBLY V2.01.11 64 P0453064 ANTI-KICKBACK FINGER SHAFT
7-1 P0453007-1 MAGNETIC SWITCH COVER ASSEMBLY 65 P0453065 ANTI-KICKBACK SHAFT COLLAR
7-3 P0453007-3 CONTACTOR NHD C-09D 230V 66 P0453066 ANTI-KICKBACK FINGER
7-4 P0453007-4 OL RELAY NHD NTH-21 17-21A 67 P0453067 FLANGE BOLT M6-1 X 12
8 P0453008 MAGNETIC SWITCH PLATE 68 P0453068 CHIP DEFLECTOR
9 P0453009 HANDWHEEL LABEL 69 P0453069 SET SCREW M6-1 X 20
11 P0453011 IDLER BRACKET COLLAR 70 P0453070 CHIP BREAKER SHAFT
12 P0453012 EXTENSION SPRING 71 P0453071 FLANGE BOLT M6-1 X 12
13 P0453013 CAP SCREW M6-1 X 8 72 P0453072 HOLD DOWN PLATE
14 P0453014 HANGER 73 P0453073 HEX NUT M6-1
15 P0453015 SHAFT 74 P0453074 SET SCREW M6-1 X 18
16 P0453016 BRACKET 75 P0453075 CHIP BREAKER
17 P0453017 IDLER PULLEY 76 P0453076 HEX NUT M12-1.75
18 P0453018 IDLER MOUNTING SHAFT 77 P0453077 LOCK WASHER 12MM
20 P0453020 HANDWHEEL COLLAR 78 P0453078 EXT RETAINING RING 12MM
21 P0453021 STAR KNOB M8-1.25 79 P0453079 LOCKING ROD
25 P0453025 BELT COVER 80 P0453080 OUTFEED ROLLER SPROCKET
26 P0453026 FLANGE BOLT M6-1 X 12 81 P0453081 OUTFEED ROLLER
27 P0453027 HEX STANDOFF 82 P0453082 HEX BOLT M6-1 X 16
28 P0453028 BELT GUARD 83 P0453083 FLAT WASHER 6MM
29 P0453029 FLANGE BOLT M6-1 X 10 84 P0453084 INFEED ROLLER SPROCKET
30 P0453030 SAFETY HATCH 86 P0453086 HEX BOLT M8-1.25 X 16
31 P0453031 CAP SCREW M8-1.25 X 45 88 P0453088 HEX NUT M5-.8
33 P0453033 CHAIN DRIVE COVER 89 P0453089 SET SCREW M5-.8 X 12
34 P0453034 POINTER 90 P0453090 PLATE
35 P0453035 PHLP HD SCR M6-1 X 12 91 P0453091 OILER SET SCREW
36 P0453036 FLAT WASHER 6MM 92 P0453092 COMPRESSION SPRING
37 P0453037 PHLP HD SCR M6-1 X 12 93 P0453093 ROLLER BUSHING BLOCK
38 P0453038 HANDWHEEL SCALE 94 P0453094 KEY 5 X 5 X 16
39 P0453039 HANDWHEEL HANDLE 95 P0453095 INFEED ROLLER
40 P0453040 HANDWHEEL 96 P0453096 KEY 8 X 8 X 35
41 P0453041 HEX NUT M12-1.75 97 P0453097 MOTOR PULLEY MX
42 P0453042 FLAT WASHER 12MM 98 P0453098 HEX BOLT M8-1.25 X 20
43 P0453043 KEY 4 X 4 X 20 99 P0453099 COLLAR
44 P0453044 WORM GEAR 100 P0453100 CUTTERHEAD PULLEY MX
45 P0453045 BALL BEARING 6201ZZ 101 P0453101 E-CLIP 8MM
46 P0453046 INT RETAINING RING 32MM 102 P0453102 KNIFE JIG SHAFT
47 P0453047 CAP SCREW M5-.8 X 55 103 P0453103 KNIFE JIG FOOT
48 P0453048 WORM HOUSING 104 P0453104 KNIVES 3-PC SET 15" X 1" X 1/8"
48A P0453048A WORM HOUSING ASSEMBLY 105 P0453105 GIB SCREW
49 P0453049 RETURN ROLLER 106 P0453106 GIB
50 P0453050 CAP SCREW M5-.8 X 14 107 P0453107 JACK SCREW M5-.8 X 12
51A P0453051A ROLLER STAND 3.505" V2.01.08 108 P0453108 ADJUSTING NUT
52 P0453052 FLAT WASHER 6MM 109 P0453109 BALL BEARING 6205ZZ
53 P0453053 HEX NUT M6-1 110 P0453110 BALL BEARING 6204ZZ
54 P0453054 HEX BOLT M6-1 X 10 111 P0453111 KNIFE CUTTERHEAD 15"
55 P0453055 CAP SCREW M8-1.25 X 20 112 P0453112 HEAD CASTING
56 P0453056 DUST HOOD 118 P0453118 KNIFE SETTING JIG ASSEMBLY
57 P0453057 FOAM PIECE 119V2 P0453119V2 POWER CORD 12G 3W 72" 6-20P V2.08.12
