-54-
G0453/G0454 (Mfg. Since 3/08)
G0453 Cabinet Stand Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
401 P0453401 RUBBER FOOT 430A-2 P0453430A-2 MOTOR FAN V2.03.08
401-1 P0453401-1 HEX NUT 3/8-16 430A-4 P0453430A-4 R CAPACITOR 20M 400V V2.03.08
402 P0453402 PLASTIC GROMMET 430A-5 P0453430A-5 S CAPACITOR 200M 250V V2.03.08
405 P0453405 UNIVERSAL WHEEL 78MM DIA 430A-6 P0453430A-6 JUNCTION BOX V2.03.08
406 P0453406 HEX NUT M8-1.25 430A-7 P0453430A-7 BALL BEARING 6205ZZ
407 P0453407 FLAT WASHER 8MM 430A-8 P0453430A-8 BALL BEARING 6203ZZ
408 P0453408 HEX BOLT M8-1.25 X 65 430A-9 P0453430A-9 CENTRIFUGAL SWITCH 16MM 3450
409 P0453409 SLEEVE 430A-10 P0453430A-10 CONTACT PLATE16MM
410 P0453410 EXT RETAINING RING 9MM 431 P0453431 FLAT WASHER 12MM
411 P0453411 FLAT WASHER 12MM 432 P0453432 HEX NUT M12-1.75
412 P0453412 SHAFT 12MM 433 P0453433 ADJUST BOLT
413 P0453413 PEDAL 434 P0453434 SET SCREW M6-1 X 8
414 P0453414 HEX NUT M8-1.25 435 P0453435 LOCK COLLAR
415 P0453415 HEX BOLT M8-1.25 X 100 436 P0453436 SET SCREW M8-1.25 X 12
416 P0453416 FLAT WASHER 8MM 437 P0453437 PLATE CONNECTING ROD
417 P0453417 HEX BOLT M8-1.25 X 50 437-1 P0453437-1 BUSHING
418 P0453418 BRACKET 438 P0453438 SET SCREW M6-1 X 12
419 P0453419 INT RETAINING RING 35MM 439 P0453439 MOTOR MOUNT PLATE
420 P0453420 BALL BEARING 6202-2RS 440 P0453440 PHLP HD SCR M6-1 X 20
421 P0453421 TROLLEY WHEEL 441 P0453441 CABINET COVER
422 P0453422 TROLLEY WHEEL SLEEVE 442 P0453442 CABINET STAND
423 P0453423 LOCK NUT M12-1.75 443 P0453443 HEX BOLT M12-1.75 X 120
424 P0453424 FLAT WASHER 10MM 444 P0453444 FLAT WASHER 10MM
425 P0453425 TROLLEY WHEEL BOLT 445 P0453445 HEX NUT M10-1.5
426 P0453426 TROLLEY UNIVERSAL KIT 448A P0453448A PEDAL ASSEMBLY
427 P0453427 HEX BOLT M8-1.25 X 45 449 P0453449 KEY 5 X 5 X 30
428 P0453428 HEX NUT M8-1.25 450 P0453450 BALL STRAIN RELIEF
429 P0453429 FLAT WASHER 8MM 453 P0453453 HEX BOLT M10-1.5 X 70
430A P0453430A MOTOR 3HP 240V 1-PH V2.03.08 454 P0453454 PLATE CONNECTING ROD
430A-1 P0453430A-1 MOTOR FAN COVER V2.03.08
