Grizzly G0454 User Manual

-58-
G0453/G0454 (Mfg. Since 3/08)
G0454 Headstock Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0454001 COGGED V-BELT MX-60 48A P0454048A WORM HOUSING ASSEMBLY
2 P0454002 CAP SCREW M6-1 X 12 49 P0454049 RETURN ROLLER
3V2 P0454003V2 MAG SWITCH ASSEMBLY V2.01.11 50 P0454050 CAP SCREW M6-1 X 16
3-1 P0454003-1 MAG SWITCH FRONT COVER 51 P0454051 ROLLER STAND
3-2 P0454003-2 MAG SWITCH BRACKET 52 P0454052 FLANGE BOLT M6-1 X 12
3-3 P0454003-3 CONTACTOR NHD C-35D 220V 53 P0454053 DUST HOOD
3-4V2 P0454003-4V2 OL RELAY NHD NTH-32 28-32A V2.08.12 54 P0454054 TOP COVER GASKET
3-5 P0454003-5 MAG SWITCH REAR COVER 55 P0454055 FLANGE BOLT M6-1 X 12
4 P0454004 CHAIN 06B-1 X 67 56 P0454056 TOP COVER
5 P0454005 CAP SCREW M6-1 X 10 57 P0454057 HEX BOLT M5-.8 X 12
6 P0454006 HANDWHEEL LABEL 58 P0454058 CUT LIMIT PLATE
8 P0454008 OIL LEVEL LABEL 59 P0454059 SET SCREW M8-1.25 X 12
9 P0454009 IDLER BRACKET COLLAR 60 P0454060 E-CLIP 15MM
10 P0454010 EXTENSION SPRING 61 P0454061 ANTI-KICKBACK FINGER SHAFT
11 P0454011 HANGER 62 P0454062 ANTI-KICKBACK SHAFT COLLAR
12 P0454012 ROLL PIN 6 X 20 63 P0454063 ANTI-KICKBACK FINGER
13 P0454013 BRACKET 64 P0454064 FLAT WASHER 6MM
14 P0454014 IDLER PULLEY 65 P0454065 FLANGE BOLT M6-1 X 15
15 P0454015 IDLER MOUNTING SHAFT 66 P0454066 CHIP DEFLECTOR PLATE
17 P0454017 HANDWHEEL COLLAR 67 P0454067 FLANGE BOLT M6-1 X 12
18 P0454018 HEX BOLT M6-1 X 12 68 P0454068 HOLD DOWN PLATE
19 P0454019 FLAT WASHER 6MM 69 P0454069 HEX NUT M6-1
20 P0454020 STAR KNOB M8-1.25 70 P0454070 SET SCREW M6-1 X 20
24 P0454024 BELT COVER 71 P0454071 SET SCREW M6-1 X 12
25 P0454025 HEX NUT M8-1.25 72 P0454072 ADJUSTING SHAFT
26 P0454026 FLAT WASHER 8MM 73 P0454073 HEX BOLT M8-1.25 X 20
27 P0454027 HEX STANDOFF 74 P0454074 LOCK WASHER 8MM
28 P0454028 BELT GUARD 75 P0454075 PRESSURE BAR
29 P0454029 FLANGE BOLT M6-1 X 10 76 P0454076 CHIP BREAKER BRACKET
30 P0454030 SAFETY HATCH 77 P0454077 SET SCREW M6-1 X 16
32 P0454032 CAP SCREW M8-1.25 X 40 78 P0454078 PRESSURE PLATE SHAFT
34 P0454034 CHAIN DRIVE COVER 79 P0454079 FLANGE BOLT M6-1 X 12
35 P0454035 CUT LIMITER POINTER 80 P0454080 PLATE SPRING
36 P0454036 PHLP HD SCR M6-1 X 12 81 P0454081 HEX NUT M6-1
37 P0454037 FLAT WASHER 6MM 82 P0454082 SET SCREW M6-1 X 20
38 P0454038 HANDWHEEL SCALE 83 P0454083 CHIP BREAKER
39 P0454039 HANDLE 84 P0454084 HEX NUT M12-1.75
40 P0454040 HANDWHEEL 85 P0454085 LOCK WASHER 12MM
41 P0454041 HEX NUT M12-1.75 86 P0454086 EXT RETAINING RING 12MM
42 P0454042 FLAT WASHER 12MM 87 P0454087 LOCK ROD
43 P0454043 KEY 4 X 4 X 20 88 P0454088 OUTFEED ROLLER SPROCKET
44 P0454044 WORM GEAR 89 P0454089 OUTFEED ROLLER
45 P0454045 BALL BEARING 6201ZZ 90 P0454090 HEX BOLT M6-1 X 16
46 P0454046 INT RETAINING RING 32MM 91 P0454091 FLAT WASHER 6MM
47 P0454047 CAP SCREW M5-.8 X 55

Grizzly G0454 Specifications

General

Brand	Grizzly
Model	G0454
Category	Planer
Language	English
