-59-
G0453/G0454 (Mfg. Since 3/08)
G0454 Headstock Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
92 P0454092 INFEED ROLLER SPROCKET 105A P0454105A MOTOR PULLEY MX V2.09.07
93 P0454093 HEX NUT M6-1 106 P0454106 CUTTERHEAD PULLEY MX
94 P0454094 SET SCREW M6-1 X 20 107 P0454107 E-CLIP 8MM
95 P0454095 HEX BOLT M8-1.25 X 20 108 P0454108 KNIFE JIG SHAFT
96 P0454096 ADJUSTMENT PLATE 109 P0454109 KNIFE JIG FOOT
97 P0454097 OILER SET SCREW 109A P0454109A KNIFE SETTING JIG ASSEMBLY
98 P0454098 COMPRESSION SPRING 110 P0454110 KNIVES 20" X 1" X 1/8" 4-PC SET
99 P0454099 FEED ROLLER BLOCK 111 P0454111 COMPRESSION SPRING
100 P0454100 KEY 5 X 5 X 22 112 P0454112 GIB SCREW
101 P0454101 INFEED ROLLER 113 P0454113 GIB
102 P0454102 HEX BOLT M8-1.25 X 25 114 P0454114 JACK SCREW M5-.8 X 12
103 P0454103 CUTTER PULLEY FLAT WASHER 115 P0454115 BALL BEARING 6206ZZ
104 P0454104 KEY 8 X 8 X 35 116 P0454116 CUTTERHEAD 20" 4-KNIFE
105A P0454105A MOTOR PULLEY MX V2.09.07 117 P0454117 HEAD CASTING
105-1 P0454105-1 MOTOR PULLEY WASHER 124V2 P0454124V2
POWER CORD 12G 3W 72" L6-30P V2.08.12
105-2 P0454105-2 TAPERED HEAD SCREW
