-63-
G0453/G0454 (Mfg. Since 3/08)
G0454 Cabinet Stand Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
401 P0454401 RELIEF BUSHING 429-2 P0454429-2 MOTOR FAN
404 P0454404 UNIVERSAL WHEEL 78MM DIA 429-4 P0454429-4 S CAPACITOR 300M 250V
405 P0454405 HEX NUT M8-1.25 429-5 P0454429-5 R CAPACITOR 60M 450V
406 P0454406 FLAT WASHER 8MM 429-6 P0454429-6 MOTOR WIRING JUNCTION BOX
407 P0454407 HEX BOLT M8-1.25 X 65 429-7 P0454429-7 BALL BEARING 6206ZZ
408 P0454408 SLEEVE 429-8 P0454429-8 BALL BEARING 6204ZZ
409 P0454409 E-CLIP 9MM 429-9 P0454429-9 CENTRIFUGAL SWITCH 19MM 3450
410 P0454410 FLAT WASHER 12MM 429-10 P0454429-10 CONTACT PLATE 19MM
411 P0454411 SHAFT 12MM 430 P0454430 FLAT WASHER 12MM
412 P0454412 PEDAL 431 P0454431 HEX NUT M12-1.75
413 P0454413 HEX NUT M8-1.25 432 P0454432 ADJUST BOLT
414 P0454414 HEX BOLT M8-1.25 X 100 433 P0454433 SET SCREW M6-1 X 8
415 P0454415 FLAT WASHER 8MM 434 P0454434 CONNECTING ROD LOCK COLLAR
416 P0454416 HEX BOLT M8-1.25 X 50 436 P0454436 PLATE CONNECTING ROD
417 P0454417 BRACKET 437 P0454437 SET SCREW M6-1 X 12
418 P0454418 INT RETAINING RING 35MM 438 P0454438 MOTOR MOUNT PLATE
419 P0454419 BALL BEARING 6202-2RS 439 P0454439 FLAT HD SCR M6-1 X 20
420 P0454420 TROLLEY WHEEL 440 P0454440 FRONT COVER
421 P0454421 TROLLEY WHEEL SLEEVE 440A P0454440A REAR COVER
422 P0454422 LOCK NUT M12-1.75 441 P0454441 CABINET STAND
423 P0454423 FLAT WASHER 10MM 441-1 P0454441-1 HEX NUT 3/8-16
424 P0454424 TROLLEY WHEEL BOLT 441-2 P0454441-2 RUBBER FOOT
425 P0454425 TROLLEY UNIVERSAL KIT 442 P0454442 HEX BOLT M10-1.5 X 55
426 P0454426 HEX BOLT M8-1.25 X 45 443 P0454443 FLAT WASHER 10MM
427 P0454427 HEX NUT M8-1.25 444 P0454444 HEX NUT M10-1.5
428 P0454428 FLAT WASHER 8MM 447 P0454447 KEY 5 X 5 X 30
429 P0454429 MOTOR 5HP 240V 1-PH 542 P0454542 PEDAL ASSEMBLY
429-1 P0454429-1 MOTOR FAN COVER 546 P0454546 PLATE CONNECTING ROD
