G0513 Series Bandsaws
-15-
SECTION 3: SETUP
This machine presents
serious injury hazards
to untrained users. Read
through this entire manu-
al to become familiar with
the controls and opera-
tions before starting the
machine!
Your machine was carefully packaged for safe
transportation. Remove the packaging materials
from around your machine and inspect it. If you
discover any damage, please call us immediately
at (570) 546-9663
for advice.
Save the containers and all packing materials for
possible inspection by the carrier or its agent.
Otherwise, filing a freight claim can be difficult.
When you are completely satisfied with the condi-
tion of your shipment, inventory the contents.
Unpacking
Needed for Setup
The following are needed to complete the setup
process, but are not included with your machine.
Description Qty
• Additional People ....................................... 1
• Safety Glasses .........................1 per Person
• Cleaner/Degreaser ..................... As Needed
• Disposable Shop Rags ............... As Needed
• Forklift/Strap or Chain w/Lifting Hook
(Each component rated for at least 1000 lbs)
..........................................................1 Each
• 1x4 & 2x4 Shims (Optional) ...............1 Each
• Feeler Gauges 0.004", 0.016" ............ 1 Each
• Straightedge ............................................... 1
• Fine Ruler ................................................... 1
• Machinist's Square ..................................... 1
• Phillips Screwdriver #2 ............................... 1
• Hex Wrench 6mm ....................................... 1
• Dust Collection System .............................. 1
• Dust Hose 4" .............................................. 2
• Hose Clamps 4" ......................................... 2
Introduction
The bandsaw is an efficient and flexible wood-
working machine. However, the bandsaw func-
tions are inter-dependent and each one must be
properly set up and adjusted so that the entire
machine operates correctly.
For instance, in this SETUP section, you will do
an initial blade tensioning before adjusting the
blade tracking. This will also allow you to properly
adjust the table angle, positive stop, blade guides,
and support bearing.
To prepare the machine for safe cutting and good
results, take extra care when performing these
inter-dependent tasks and complete them in the
correct order.
