G0513 Series Bandsaws
-17-
Figure 10. Other bandsaw components.
D
E
F
G
I
H
G0513X2, G0513X2B, G0513X2BF, &
G0513X2F
Shipping Inventory (Figures 9 & 10): Qty
A. Bandsaw (not shown) ................................. 1
B. Table ........................................................... 1
C. Miter Gauge ................................................ 1
D. Rear Rail .................................................... 1
E. Resaw Fence ............................................ 1
F. Front Rail .................................................... 1
G. Fence Assembly ......................................... 1
H. Foot Brake Pedal (G0513X2BF
& G0513X2F) .............................................. 1
I. Guide Post Handwheel............................... 1
Hardware & Tools (Not Shown) Qty
• Eye Bolt M10-1.5 (May Be Installed) .......... 1
• Flat Washers 8mm (Table, Fence, Rail) ..... 8
• Lock Washers 8mm (Table, Rail) ............... 5
• Hex Bolts M8-1.25 x 25 (Table) .................. 4
• Hex Bolt M8-1.25 x 90 (Positive Stop) ........ 1
• Hex Nuts M8-1.25 (Positive Stop, Fence)... 2
• Cap Screws M6-1 x 20 (Rail) ..................... 3
• Cap Screw M8-1.25 x 20 (Rail) .................. 1
• Lock Washers 6mm (Rail) .......................... 3
• Flat Washers 6mm (Rail) ............................ 3
• Hex Nut M6-1 (Fence) ................................ 1
• Cap Screws M6-1 x 16 (Foot Brake Pad) ... 2
• Lock Washers 6mm (Foot Brake Pad) ....... 2
• Table Pin..................................................... 1
• Table Insert ................................................. 1
• Fence Handle M8-1.25 x 44 (Fence) .......... 1
• Rail Pad M6-1 x 18 (Fence) ........................ 1
• Moving Plate (Fence).................................. 1
• Rail Plates .................................................. 3
• Hex Wrench 5mm, 8mm....................1 Each
• Open End Wrench 10 x 13mm ................... 1
Figure 9. Table and miter gauge.
