G0513 Series Bandsaws
-75-
G0513/G0513P/G0513ANV Main Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
4 P0513004 LIFTING EYE BOLT M10-1.5 58 P0513058 WHEEL BRUSH
5 P0513005 MACHINE BODY (G0513) 59 PB10M HEX BOLT M6-1 X 25
5 P0513P005 MACHINE BODY (G0513P) 60 P0513060 STAR KNOB
5 P0513ANV005 MACHINE BODY G0513ANV) 61 PLN03M LOCK NUT M6-1
8 PW03M FLAT WASHER 6MM 62 P0513062 STRAIN RELIEF 16MM STRAIGHT LT
9 P0513009 POWER CORD 14G 3W 72" 63 P0513063 HEIGHT POINTER
10 PN01M HEX NUT M6-1 64 PN03M HEX NUT M8-1.25
11 P0513011 POINTER 65 PB45M HEX BOLT M8-1.25 X 100
12 P0513012 STEP SCREW M4-.7 X 5 66 P0513066 STAR KNOB BOLT M10-1.5 X 20
13 P0513013 HINGE SHAFT 67 P0513067 STAR KNOB BOLT M10-1.5 X 55
14 PRP10M ROLL PIN 5 X 36 68 P0513068 THREADED HANDLE M10-1.5
15 P0513015 UPPER WHEEL SHAFT HINGE 69 P0513069 CAM
16 P0513016 UPPER WHEEL SHAFT 70 P0513070 PILLOW BLOCK
17 P0513017 BUSHING 71 P0513071 HANDLE M12-1.75
18 P6204-2RS BALL BEARING 6204-2RS 72 P0513072 LEVER
19 P0513019 UPPER WHEEL 17" 73 PN09M HEX NUT M12-1.75
20 PR25M INT RETAINING RING 47MM 74 P0513074 LEVER HUB
21 P0513X021 WHEEL FLAT WASHER 8MM 75 PCAP14M CAP SCREW M8-1.25 X 20
22 PB26M HEX BOLT M8-1.25 X 30 76 PLW04M LOCK WASHER 8MM
23 P0513023 SAW BLADE 131.5" X 1/2" 6TPI HOOK 78 P0513078 SHAFT COVER
24 PLW04M LOCK WASHER 8MM 79 PSS09M SET SCREW M8-1.25 X 20
25 PB29M HEX BOLT M6-1 X 30 80 PN03M HEX NUT M8-1.25
26 T23071 URETHANE TIRE 17" 1-PAIR 81 P0513081 LOWER WHEEL SHAFT
27 P0513027 LOWER WHEEL 17" 82 P0513082 MOTOR 2HP 110V/220V 1-PH
28 P0513028 LOWER WHEEL PULLEY 82-1 P0513082-1 MOTOR FAN COVER
29 PN32 HEX NUT 1-14 82-2 P0513082-2 MOTOR FAN
30 PLW09 LOCK WASHER 1" 82-3V2 PC300T S CAPACITOR 300M 250V 1-1/2 X 2-3/8 V2.01.10
31 P0513031 MOTOR CORD 14G 3W 82-4 P0513082-4 S CAPACITOR COVER
32 P0513032 COMPRESSION SPRING 7 X 8 X 90 82-5V2 PC040H R CAPACITOR 40M 250V 1-1/2 X 2-3/4 V2.01.10
33 PRP02M ROLL PIN 3 X 16 82-6 P0513082-6 R CAPACITOR COVER
34 P0513034 ALIGNMENT PLATE 82-7 P0513082-7 MOTOR JUNCTION BOX
35 P51201 THRUST BEARING 51201 82-8 PCP001 CONTACT PLATE
36 P0513036 2-BUTTON POWER SWITCH 82-9 PCS001 CENTRIFUGAL SWITCH 5/8-1725
37 P0513037 TENSION HANDWHEEL 82-9A P0513082-9A CENTRIFUGAL SWITCH W/CONT PLATE
38 P0513038 TENSION ADJUSTING ROD 82-10 P6203ZZ BALL BEARING 6203ZZ
39 PFS07M FLANGE SCREW M5-.8 X 10 82-11 P6205ZZ BALL BEARING 6205ZZ
40 PTLW02M EXT TOOTH WASHER 5MM 83 PB95M HEX BOLT M5-.8 X 16
41 PN06M HEX NUT M5-.8 84 PLW01M LOCK WASHER 5MM
42 PFS08M FLANGE SCREW M5-.8 X 16 85 P0513085 MOTOR MOUNT BRACKET
43 P0513043 SWITCH BACK PLATE 86 PCAP14M CAP SCREW M8-1.25 X 20
44 PB03M HEX BOLT M8-1.25 X 16 87 P0513087 STRAIN RELIEF PLATE 2-HOLE
45 PW01M FLAT WASHER 8MM 88 PFS07M FLANGE SCREW M5-.8 X 10
46 P0513046 UPPER WHEEL SLIDING BRACKET 89 P0513089 PILLOW BLOCK
47 PB10M HEX BOLT M6-1 X 25 90 PK15M KEY 5 X 5 X 35
48 PRIV005M STEEL BLIND RIVET 3 X 13MM 91 PB81M HEX BOLT M8-1.25 X 20 LH
49 PB04M HEX BOLT M6-1 X 10 92 P0513092 MOTOR PULLEY TYPE-A 3.5"
50 P0513050 CLEAR WINDOW 93 PVA42 V-BELT A42
55 P0513055 UPPER WHEEL COVER (G0513) 94 PB04M HEX BOLT M6-1 X 10
55 P0513P055 UPPER WHEEL COVER (G0513P) 95 P0513095 LOWER WHEEL COVER (G0513)
55 P0513ANV055 UPPER WHEEL COVER (G0513ANV) 95 P0513P095 LOWER WHEEL COVER (G0513P)
55A P0513X2055A UPPER WHEEL COVER ASSY (G0513) 95 P0513ANV095 LOWER WHEEL COVER (G0513ANV)
55A P0513P055A UPPER WHEEL COVER ASSY (G0513P) 97 PW01M FLAT WASHER 8MM
55A P0513ANV055A UPPER WHEEL COVER ASSY (G0513ANV) 119 PW01M FLAT WASHER 8MM
56 PB04M HEX BOLT M6-1 X 10 152 PB08M HEX BOLT M6-1 X 20
57 PW03M FLAT WASHER 6MM 175 PB08M HEX BOLT M6-1 X 20
176 P0513176 BUSHING
