G0513 Series Bandsaws
-79-
G0513/G0513P/G0513ANV Upper Blade
Guides & Miter Gauge Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
6 PSS07M SET SCREW M5-.8 X 5 160 P0513160 PINION GEAR STEP BOLT
134 P0513134 GUIDE ADJUSTMENT SHAFT 161V2 P0513161V2 THREADED BUSHING V2.06.09
136 PCAP148M CAP SCREW M8-1.25 X 80 162 PCAP14M CAP SCREW M8-1.25 X 20
137 PW01M FLAT WASHER 8MM 163 PLW04M LOCK WASHER 8MM
138 P0513138 UPPER BLADE GUARD (G0513/G0513P) 164V2 P0513164V2 THREADED GUIDE BRACKET 14MM V2.06.09
138 P0513ANV138 UPPER BLADE GUARD (G0513ANV) 165 P0513165 WORM CYLINDER
138-1 P0513138-1 BLADE GUARD SCALE 166 P0513166 FIXED PLATE
140 P0513012 STEP SCREW M4-.7 X 5 167 P0513167 PINION GEAR 15T
141 P0513141 FIBER WASHER 5MM 168 P0513168 PINION GEAR STEP BOLT
142 P0513142 SLIDING PLATE (G0513/G0513P) 169 P0513169 BRACKET COVER
142 P0513ANV142 SLIDING PLATE (G0513ANV) 170 PCAP11M CAP SCREW M8-1.25 X 16
143 PR05M EXT RETAINING RING 15MM 171 PS07M PHLP HD SCR M4-.7 X 8
144 P6202ZZ BALL BEARING 6202ZZ 172 PSS11M SET SCREW M6-1 X 16
145 P0513145 UPPER BLADE GUIDE SUPPORT 173 P0513173 MITER GAUGE ASSY
146 P0513133 BLADE GUIDE 173-1 P0513173-1 GUIDE BAR
147 PTS001M THUMB SCREW M6-1 X 16 173-2 P1022029-1 T-SLOT WASHER 5MM
149 PCAP28M CAP SCREW M6-1 X 15 173-3 P0506147 INDICATOR
150 P0513150 ADJUSTMENT SHAFT 173-4 P0513173-4 NYLON WASHER 1/4"
151 P0513151 UPPER SPACING SLEEVE 173-5 P0513173-5 MITER GAUGE HANDLE 1/4"-20
153 P0513153 UPPER GUIDE SUPPORT BLOCK 173-6 P0513173-6 MITER GAUGE BODY
154 PS38M PHLP HD SCR M4-.7 X 10 173-7 P0513173-7 INDEXING PIN
155 PN04M HEX NUT M4-.7 173-8 PS37M PHLP HD SCR M6-1 X 6
156 P0513156 RACK 173-9 PFS01M FLANGE SCREW M5-.8 X 8
157A P0513157A GUIDE POST ASSEMBLY 174 P0513174 BUSHING
157 P0513157 GUIDE POST 192 PAW05M HEX WRENCH 5MM
158 P0513158 ELEVATION HANDWHEEL 193 PAW08M HEX WRENCH 8MM
159 PB08M HEX BOLT M6-1 X 20 194 PWR1013 WRENCH 10 X 13MM OPEN-END
