Grizzly G0513 SERIES User Manual

-84-
G0513 Series Bandsaws
G0513X2 Main Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
2 PSS01M SET SCREW M6-1 X 10 55 P0513055 UPPER WHEEL COVER
3 P0513X003 BUSHING 56 PB10M HEX BOLT M6-1 X 25
4 P0513004 LIFTING EYE BOLT M10-1.5 57 PW03M FLAT WASHER 6MM
5 P0513005 MACHINE BODY 58 P0513058 WHEEL BRUSH
7 P0513X007 BUSHING 59 PCAP06M CAP SCREW M6-1 X 25
8 PW03M FLAT WASHER 6MM 60 P0513060 STAR KNOB
9 P0513009 POWER CORD 14G 3W 72" 61 PLN03M LOCK NUT M6-1
10 PN01M HEX NUT M6-1 62 P0513062 STRAIN RELIEF 16MM STRAIGHT LT
11 P0513011 POINTER 63 P0513063 HEIGHT POINTER
12 P0513012 STEP SCREW M4-.7 X 5 64 PN03M HEX NUT M8-1.25
13 P0513013 HINGE SHAFT 65 PB124M HEX BOLT M8-1.25 X 90
14 PRP10M ROLL PIN 5 X 36 66 P0513066 STAR KNOB BOLT M10-1.5 X 20
15 P0513015 UPPER WHEEL SHAFT HINGE 67 P0513067 STAR KNOB BOLT M10-1.5 X 55
16 P0513016 UPPER WHEEL SHAFT 68 P0513068 THREADED HANDLE M10-1.5
17 P0513X2B017 UPPER WHEEL ASSEMBLY 69 P0513069 CAM
17-1 P0513017 BUSHING 70 P0513070 PILLOW BLOCK
17-2 P6204-2RS BALL BEARING 6204-2RS 71 P0513071 HANDLE M12-1.75
17-3 PR25M INT RETAINING RING 47MM 72 P0513072 LEVER
17-4 P0513X019 UPPER WHEEL 17" 73 PN09M HEX NUT M12-1.75
17-5 T23071 URETHANE TIRE 17" 1-PAIR 74 P0513074 LEVER HUB
18 P0513X2B018 LOWER WHEEL ASSEMBLY 75 PBHS22M BUTTON HD CAP SCR M8-1.25 X 20
18-1 P0513017 BUSHING 76 PLW04M LOCK WASHER 8MM
18-2 P6204-2RS BALL BEARING 6204-2RS 78 P0513078 SHAFT COVER
18-3 PR25M INT RETAINING RING 47MM 79 PSS09M SET SCREW M8-1.25 X 20
18-4 P0513X027 LOWER WHEEL 17" 80 PN03M HEX NUT M8-1.25
18-5 T23071 URETHANE TIRE 17" 1-PAIR 81 P0513081 LOWER WHEEL SHAFT
21 P0513X021 WHEEL FLAT WASHER 8MM 82V2 P0513X2082V2 MOTOR 2HP 110V/220V 1-PH V2.01.10
22 PCAP11M CAP SCREW M8-1.25 X 16 82-1V2 P0513X2082-1V2 MOTOR FAN COVER V2.01.10
23 P0513023 SAW BLADE 131.5" X 1/2" 6TPI HOOK 82-2V2 P0513X2082-2V2 MOTOR FAN V2.01.10
24 PLW04M LOCK WASHER 8MM 82-3V2 PC300T S CAPACITOR 300M 250V 1-1/2 X 2-3/8 V2.01.10
25 PCAP14M CAP SCREW M8-1.25 X 20 82-4V2 P0513X2082-4V2 S CAPACITOR COVER V2.01.10
28 P0513028 LOWER WHEEL PULLEY 82-5V2 PC040G R CAPACITOR 40M 250V 1-3/8 X 2-5/8 V2.01.10
29 PN32 HEX NUT 1-14 82-6V2 P0513X2082-6V2 R CAPACITOR COVER V2.01.10
30 PLW09 LOCK WASHER 1" 82-7V2 P0513X2082-7V2 MOTOR JUNCTION BOX V2.01.10
31 P0513031 MOTOR CORD 14G 3W 82-8 PCP001 CONTACT PLATE 5/8
32 P0513032 COMPRESSION SPRING 7 X 8 X 90 82-9 PCS001 CENTRIFUGAL SWITCH 5/8-1725
33 PRP02M ROLL PIN 3 X 16 82-10 P6203ZZ BALL BEARING 6203ZZ
34 P0513034 ALIGNMENT PLATE 82-11 P6205ZZ BALL BEARING 6205ZZ
35 P51201 THRUST BEARING 51201 83 PB32M HEX BOLT M10-1.5 X 25
36 P0513036 2-BUTTON POWER SWITCH 84 PLW06M LOCK WASHER 10MM
37 P0513037 TENSION HANDWHEEL 85 P0513085 MOTOR MOUNT BRACKET
38 P0513038 TENSION ADJUSTING ROD 86 PBHS22M BUTTON HD CAP SCR M8-1.25 X 20
39 PFS07M FLANGE SCREW M5-.8 X 10 87 P0513087 STRAIN RELIEF PLATE 2-HOLE
40 PTLW02M EXT TOOTH WASHER 5MM 88 PFS07M FLANGE SCREW M5-.8 X 10
41 PN06M HEX NUT M5-.8 89 P0513089 PILLOW BLOCK
42 PFS08M FLANGE SCREW M5-.8 X 16 90 PK15M KEY 5 X 5 X 35
43 P0513043 SWITCH BACK PLATE 91 PB81M HEX BOLT M8-1.25 X 20 LH
44 PCAP11M CAP SCREW M8-1.25 X 16 92 P0513092 MOTOR PULLEY TYPE-A 3.5"
45 PWF08M FENDER WASHER 8MM 93 PVA42 V-BELT A42
46 P0513046 UPPER WHEEL SLIDING BRACKET 94 PCAP04M CAP SCREW M6-1 X 10
47 PCAP05M CAP SCREW M8-1.25 X 50 95A P0513095 LOWER WHEEL COVER
48 PRIV005M STEEL BLIND RIVET 3 X 13MM 97 PWF08M FENDER WASHER 8MM
49 PCAP04M CAP SCREW M6-1 X 10 111 PCAP02M CAP SCREW M6-1 X 20
50 P0513050 CLEAR WINDOW 119 PLW02M LOCK WASHER 4MM
55A P0513X2055A UPPER WHEEL COVER ASSY
