G0513 Series Bandsaws
-91-
G0513X2BF Main Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
2 PSS01M SET SCREW M6-1 X 10 46 P0513046 UPPER WHEEL SLIDING BRACKET
3 P0513X003 BUSHING 47 PCAP06M CAP SCREW M6-1 X 25
4 P0513004 LIFTING EYE BOLT M10-1.5 48 PRIV005M STEEL BLIND RIVET 3 X 13MM
5 P0513X2F005 MACHINE BODY 49 PCAP04M CAP SCREW M6-1 X 10
7 P0513X007 BUSHING 50 P0513050 CLEAR WINDOW
8 PW03M FLAT WASHER 6MM 51 P0513X2B051 KEY SWITCH
10 PN01M HEX NUT M6-1 55A P0513X2055A UPPER WHEEL COVER ASSY
11 P0513011 POINTER 55 P0513055 UPPER WHEEL COVER
12 P0513012 STEP SCREW M4-.7 X 5 56 PB10M HEX BOLT M6-1 X 25
13 P0513013 HINGE SHAFT 57 PW03M FLAT WASHER 6MM
14 PRP91M ROLL PIN 5 X 35 58 P0513058 WHEEL BRUSH
15 P0513015 UPPER WHEEL SHAFT HINGE 59 PCAP06M CAP SCREW M6-1 X 25
16 P0513016 UPPER WHEEL SHAFT 60 P0513060 STAR KNOB
17 P0513X2B017 UPPER WHEEL ASSEMBLY 61 PLN03M LOCK NUT M6-1
17-1 P0513017 BUSHING 62 P0513062 STRAIN RELIEF 16MM STRAIGHT LT
17-2 P6204-2RS BALL BEARING 6204-2RS 63 P0513063 HEIGHT POINTER
17-3 PR25M INT RETAINING RING 47MM 64 PN03M HEX NUT M8-1.25
17-4 P0513X019 UPPER WHEEL 17" 65 PB124M HEX BOLT M8-1.25 X 90
17-5 T23071 URETHANE TIRE 17" 1-PAIR 66 P0513066 STAR KNOB BOLT M10-1.5 X 20
18 P0513X2B018 LOWER WHEEL ASSEMBLY 67 P0513067 STAR KNOB BOLT M10-1.5 X 53
18-1 P0513017 BUSHING 68 P0513068 THREADED HANDLE M10-1.5
18-2 P6204-2RS BALL BEARING 6204-2RS 69 P0513069 CAM
18-3 PR25M INT RETAINING RING 47MM 70 P0513070 PILLOW BLOCK
18-4 P0513X027 LOWER WHEEL 17" 71 P0513071 HANDLE M12-1.75
18-5 T23071 URETHANE TIRE 17" 1-PAIR 72 P0513072 LEVER
19 P0513X2BF019 MAG SWITCH ASSY SDE MPE-18 220V 73 PN09M HEX NUT M12-1.75
19-1 P0513X2B019-2 CONTACTOR SDE MA-18 220V 74 P0513074 LEVER HUB
19-2 P0513X2B019-3 OL RELAY SDE RA-20 8-12A 75 PBHS22M BUTTON HD CAP SCR M8-1.25 X 20
19-3 P0513X2BF019-3 MAG SWITCH COVER ASSEMBLY 76 PLW04M LOCK WASHER 8MM
19-4 P0513X2B019-6V2 CONTROL CORD 16G 5W V2.05.11 78 P0513078 SHAFT COVER
19-5 P0513X2B019-7 MOTOR CORD 14G 5W 79 PSS09M SET SCREW M8-1.25 X 20
19-6 PS09M PHLP HD SCR M5-.8 X 10 80 PN03M HEX NUT M8-1.25
21 P0513X021 WHEEL FLAT WASHER 8MM 81 P0513X2F081 LOWER WHEEL SHAFT
22 PCAP11M CAP SCREW M8-1.25 X 16 82 P0513X2BF082 MOTOR 2HP 220V 1-PH W/BRAKE
23 P0513023 SAW BLADE 131.5" X 1/2" 6TPI HOOK 82-2 P0513X2BF082-2 MOTOR FAN COVER
24 PLW04M LOCK WASHER 8MM 82-3 P0513X2BF082-3 MOTOR FAN
25 PCAP14M CAP SCREW M8-1.25 X 20 82-4 P0513X2BF082-4 CAPACITOR COVER
28 P0513X2F028 WHEEL PULLEY/BRAKE DRUM 82-5 PC045C R CAPACITOR 45M 400V 2 X 2-1/2
29 PN32 HEX NUT 1-14 82-6 P0513X2BF082-6 MOTOR JUNCTION BOX
30 PLW09 LOCK WASHER 1" 82-9 P0513X2BF082-9 MAGNETIC BRAKE YZG
31 P0513X2B031 CONTROL PANEL PLATE 82-10 P0513X2BF082-10 BRAKE SHOE
32 P0513032 COMPRESSION SPRING 7 X 8 X 90 82-14 P6205ZZ BALL BEARING 6205ZZ
33 PRP02M ROLL PIN 3 X 16 82-15 P6203ZZ BALL BEARING 6203ZZ
34 P0513034 ALIGNMENT PLATE 83 PB32M HEX BOLT M10-1.5 X 25
35 P51201 THRUST BEARING 51201 84 PLW06M LOCK WASHER 10MM
36 PHTEK15M TAP SCREW M4 X 10 85 P0513085 MOTOR MOUNT BRACKET
37 P0513037 TENSION HANDWHEEL 86 PBHS22M BUTTON HD CAP SCR M8-1.25 X 20
38 P0513038 TENSION ADJUSTING ROD 87 P0513X2B087 STRAIN RELIEF PLATE 1-HOLE
39 PFS07M FLANGE SCREW M5-.8 X 10 88 PHTEK15M TAP SCREW M4 X 10
40 P0513X2B040 STOP BUTTON 89 P0513089 PILLOW BLOCK
41 P0513X2B041 START BUTTON 90 PK15M KEY 5 X 5 X 35
44 PCAP11M CAP SCREW M8-1.25 X 16 91 PB81M HEX BOLT M8-1.25 X 20 LH
45 PWF08M FENDER WASHER 8MM 92 P0513092 MOTOR PULLEY TYPE-A 3.5"
