Grizzly G0555LX User Manual

-58-
G0555LX (Mfg. Since 3/13)
Main Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0555LX001 BASE 42 PLN16 LOCK NUT 1/2-20 THIN
2 PB64 HEX BOLT 5/8-11 X 2-1/2 43 PR21M INT RETAINING RING 35MM
3 PW14 FLAT WASHER 5/8 44 P6202-2RS BALL BEARING 6202-2RS
4 PN04 HEX NUT 5/8-11 45 P0555LX045 LOWER WHEEL
5 P0555LX005 GUIDE PIN 6 X 15MM 46 PW07 FLAT WASHER 5/16
6 P0555LX006 LOWER WHEEL SHAFT 47 PB104 HEX BOLT 5/16-18 X 3/4 LH
7 P6204-2RS BALL BEARING 6204-2RS 48 P0555LX048 LOWER WHEEL GUARD
8 PK23M KEY 5 X 5 X 25MM 49 P0555LX049 KNOB 5/16-18
9 PW07 FLAT WASHER 5/16 50 PTLW03M INT TOOTH WASHER 8MM
10 PB32 HEX BOLT 5/16-18 X 5/8 51 P0555LX051 STUD LATCH
11 P0555LX011 MOTOR 1HP 110V/220V 1PH 55 PS01 PHLP HD SCR 10-24 X 1/2
11-1 P0555LX011-1 MOTOR FAN 56 P0555LX056 CATCH
11-2 P0555LX011-2 FAN COVER 57 P0555LX057 LOCATING BOLT
11-3 P0555LX011-3 WIRING BOX 58 PHTEK7 TAP SCREW #8 X 3/8
11-4 P0555LX011-4 CAPACITOR COVER 59 P0555LX059 FRONT UPPER COVER
11-5 P0555LX011-5 S CAPACITOR 300M 125V 60 P0555LX060 SAW BLADE 93-1/2 X 3/8 X 6TPI HOOK
11-6 P0555LX011-6 CONTACTOR PLATE 61 P0555LX061 BACK UPPER COVER
11-7 P0555LX011-7 CENTRIFUGAL SWITCH 1725 RPM 62 PFS03 FLANGE SCREW 10-24 X 3/8
11-8 P6205-2RS BALL BEARING 6205-2RS 63 P0555LX063 UPPER HINGE
11-9 P6204-2RS BALL BEARING 6204-2RS 64 P0555LX064 STANDOFF STUD-MF
12 P0555LX012 MOTOR PULLEY 65 P0555LX065 SAW BLADE GUARD
13 PSS07 SET SCREW 1/4-20 X 1/2 66 P0555LX066 BLADE GUARD WASHER #10
14 P0555LX014 PUSH BUTTON SWITCH ASSY 68 P0555LX068 RIBBED V-BELT 200J5
14-1 P0555LX014-1 SWITCH COVER 69 P0555LX069 LOWER WHEEL COVER HINGE
14-2 P0555LX014-2 SWITCH CONTROL 70 PS06 PHLP HD SCR 10-24 X 3/8
14-3 P0555LX014-3 SWITCH BOX 71 PB11 HEX BOLT 5/16-18 X 1-1/2
15 P0555LX015 TAP SCREW #10 X 1 72 PW07 FLAT WASHER 5/16
16 PW03 FLAT WASHER #10 73 PLW01 LOCK WASHER 5/16
17 PS22 PHLP HD SCR 10-24 X 5/8 74 PN02 HEX NUT 5/16-18
19 PTLW08M EXT TOOTH WASHER 10MM 75 P0555LX075 CORD CLAMP
21 P0555LX021 SWITCH PLATE 76 PS01 PHLP HD SCR 10-24 X 1/2
22 P0555LX022 WHEEL PULLEY 79 P0555LX079 UPPER BLADE GUIDE CASTING
23 PS18 PHLP HD SCR 10-24 X 1/4 80 PCAP04 CAP SCREW 1/4-20 x 1/2
24 P0555LX024 STRAIN RELIEF 81 P0555LX081 BEARING ARBOR
25 P0555LX025 POWER CORD 16G 3W 5-15 120" 82 P6000-2RS BALL BEARING 6000-2RS
26 P0555LX026 MOTOR CORD 16G 3W 83 PFH09 FLAT HD SCR 1/4-20 X 5/16
28 P0555LX028 UPPER FRAME ARM 84 P0555LX084 GUIDE POST
29 P0555LX029 KNOB BOLT 5/16-18 X 3/4 85 PLW03 LOCK WASHER 3/16
30 P0555LX030 SLIDING HOUSING 86 PCAP110 CAP SCREW 10-24 X 1-3/4
31 PWN03 WING NUT 5/16-18 88 P0555LX088 LOWER BLADE GUIDE BRACKET
33 P0555LX033 TENSION BOLT 3/8-16 X 11-5/8 89 P0555LX089 GUIDE SHAFT BRACKET
34 P0555LX034 PIVOT PIN 90 P0555LX090 UPPER BLADE GUARD
35 P0555LX035 UPPER WHEEL SHAFT 92 PS06 PHLP HD SCR 10-24 X 3/8
38 P0555LX038 COMPRESSION SPRING 93 P0555LX093 LOWER BRACKET POST
39 P0555LX039 INDICATOR NUT 3/8 X 16 94 PW06 FLAT WASHER 1/4
40 P0555LX040 UPPER WHEEL 95 PB05 HEX BOLT 1/4-20 X 3/4
41 P0555LX041 WHEEL TIRE 96 PCAP109 CAP SCREW 10-32 X 1/4
