Grizzly G0699 - Main & Scoring Motor Wiring Diagrams

-82-
Model G0699 (Mfd. Since 5/15)
READ ELECTRICAL SAFETY
ON PAGE 79!
Main & Scoring Motor Wiring Diagrams
motor wiring diagrams
Ground
U V W
9
3 64
52
8
1
7
Ground
9
3
6
4
5
2
8
1
7
Ground
1
7
8 2
3
9
6
4
5
12 10 11
W1V1U1
Ground
1
7
8
2
3
9
4
5
6
12
10
11
W1V1U1
(Additional 440V Conversion Steps Required)
220V Scoring Motor 440V Scoring Motor
220V Main Motor 440V Main Motor
(Additional 440V Conversion Steps Required)
C
D
U V W
To Electrical Cabinet
(Page 80)
To Electrical Cabinet
(Page 80)
