Grizzly G0699 - Main Blade Arbor; Hex Nut M10-1.5; Lock Washer 10 Mm

-88-
Model G0699 (Mfd. Since 5/15)
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
Main Blade Arbor
301
302
303
310
305
306V2
307
308
309
309AV2
304V2
316
329V2
330
330
337
338
339
331
332
333
334
335
336
311
317
318
319
320
321
322
323
324
325
326
327
328
REF PART # DESCRIPTION REF PART # DESCRIPTION
301 P06990301 GIB 322 P06990322 BUSHING
302 P06990302 BUTTON HD CAP SCR M10-1.5 X 25 323 P06990323 ARBOR HOUSING PIVOT SHAFT
303 P06990303 LOCK WASHER 10MM 324 P06990324 BUTTON HD CAP SCR M8-1.25 X 20
304V2 P06990304V2 CARRIAGE BOLT M10-1.5 X 35 V2.10.12 325 P06990325 BUSHING
305 P06990305 RIVING KNIFE FLAT WASHER 10MM 326 P06990326 PIVOT SHAFT FLAT WASHER
306V2 P06990306V2 RIVING KNIFE V2.10.16 327 P06990327 LOCK WASHER 8MM
307 P06990307 FRONT RIVING KNIFE BRACKET 328 P06990328 CAP SCREW M8-1.25 X 20
308 P06990308 KEY 5 X 5 X 20 329V2 P06990329V2 ARBOR-HOUSING ASSEMBLY V2.05.11
309AV2 P06990309AV2 RIVING KNIFE BRACKET ASSY V2.11.12 330 P06990330 BALL BEARING 6206 LLB
309 P06990309 BRACKET 331 P06990331 SPACER
310 P06990310 HEX NUT M10-1.5 332 P06990332 SET SCREW M6-1 X 8
311 P06990311 PIVOT LINK 333 P06990333 ARBOR PULLEY
316 P06990316 SET SCREW M5-.8 X 10 334 P06990334 ARBOR HOUSING
317 P06990317 HEX NUT M16-2 335 P06990335 WAVE WASHER
318 P06990318 MAIN BLADE ARBOR FLANGE 336 P06990336 MAIN BLADE ARBOR
319 P06990319 BUTTON HD CAP SCR M8-1.25 X 20 337 P06990337 FLAT WASHER 8MM
320 P06990320 LOCK WASHER 8MM 338 P06990338 LOCK WASHER 8MM
321 P06990321 FLAT WASHER 8MM 339 P06990339 BUTTON HD CAP SCR M8-1.25 X 20
