Model G0602/G0752 (Mfg. Since 11/12)
-9-
Model Number G0602 G0752
Headstock Information
Spindle Bore 1"
Spindle Size 1
3
⁄4"
Spindle Taper MT#4
Spindle Threads 8 TPI
Number of Spindle Speeds 6 Variable
Range of Spindle Speeds 150 – 2400 RPM 100 – 800, 160 – 1300, 250 – 2000 RPM
Spindle Type Threaded
Spindle Bearings Tapered Roller
Tailstock Information
Tailstock Quill Travel 2
1
⁄2"
Tailstock Taper MT#3
Tailstock Barrel Diameter 1.25"
Threading Information
Number of Longitudinal Feeds 9
Range of Longitudinal Feeds 0.0025 – 0.0140 in./rev.
Number of Inch Threads 33
Range of Inch Threads 8 – 72 TPI
Number of Metric Threads 26
Range of Metric Threads 0.25 – 3.50 mm
Dimensions
Bed Width 6
1
⁄8 in.
Leadscrew Diameter
3
⁄4 in.
Leadscrew TPI 12 TPI
Leadscrew Length 34"
Steady Rest Capacity
1
⁄4"– 2"
Follow Rest Capacity
1
⁄4"– 2"
Faceplate Size 8 in.
Construction
Base Cast Iron
Headstock Cast Iron
Headstock Gears Steel
Bed Hardened and Precision-Ground Cast Iron
Stand Cast Iron
Paint Epoxy
Other
Country of Origin China
Warranty 1 Year
Serial Number Location ID Label on Headstock
Approximate Assembly & Setup
Time
1 Hour
