Model G0602/G0752 (Mfg. Since 11/12)
-75-
Spindle & Drive Belt Parts
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0602001 HEADSTOCK REAR COVER 37 P0602037 PULLEY A (G0602)
2 PS17M PHLP HD SCR M4-.7 X 6 37 P0752037 MOTOR PULLEY (G0752)
3 P0602003 DEAD CENTER MT#4 38 PK11M KEY 6 X 6 X 40
5 PCAP06M CAP SCREW M6-1 X 25 39 P0602039 SPACER
6 PW03M FLAT WASHER 6MM 40 P0602040 STANDOFF STUD M10-1.5 X 50, 15, 25 (G0602)
7 P0602007 COMPRESSION SPRING 40 PB56M CAP SCREW M10-1.5 X 20 (G0752)
8 P0602008 CLAMP 41 P0602041 MOUNTING PLATE
10 PCAP06M CAP SCREW M6-1 X 25 42 PW04M FLAT WASHER 10MM
11 P0602011 SPINDLE 43 PN02M HEX NUT M10-1.5 (G0602)
12 PK135M KEY 10 X 10 X 55 44 P0602044 TENSIONER ROLLER SHAFT
13 P0602013 SPACER 45 P6001-2RS BALL BEARING 6001-2RS
14 P32009 TAPERED ROLLER BEARING 32009 46 P0602046 TENSIONER ROLLER
15 P0602015 HEADSTOCK 48 PR03M EXT RETAINING RING 12MM
16 PCAP14M CAP SCREW M8-1.25 X 20 49 P0602049 CHANGE GEAR COVER
17 P32009 TAPERED ROLLER BEARING 32009 51 PN06M HEX NUT M5-.8
18 PCAP02M CAP SCREW M6-1 X 20 52 P0602052 SPINDLE COVER
19 P0602019 SPACER 53 PS08M PHLP HD SCR M5-.8 X 12
19 P0752019 SPEED SENSOR RING W/MAGNETS 54 P0602054 3-JAW CHUCK 5"
20 P0602020 GEAR 40T PLASTIC 54-1 P0602054-1 3-JAW CHUCK JAW INT 3-PC SET
21 PVM27.5 V-BELT M-27.5 3L275 (G0602) 54-2 P0602054-2 CHUCK BACKPLATE
22 P0602022 PULLEY C 54-3 P0602054-3 3-JAW CHUCK KEY
23 PVM33 V-BELT M-33 3L330 54-4 P0602054-4 3-JAW CHUCK JAW EXT 3-PC SET
24 P0602024 SPANNER NUT 37MM 55 P0602055 4-JAW CHUCK 6.5"
25 P0602025 BRACKET PLATE 55-1 P0602055-1 4-JAW CHUCK JAWS 4-PC SET
26 PLW06M LOCK WASHER 10MM 55-2 P0602055-2 4-JAW CHUCK KEY
27 PN02M HEX NUT M10-1.5 55-3 P0602055-3 4-JAW CHUCK BACKPLATE
28 PW04M FLAT WASHER 10MM 56 P0602056 FACEPLATE 8"
29 PCAP50M CAP SCREW M5-.8 X 10 57 P0602057 DEAD CENTER MT#3
30 PW02M FLAT WASHER 5MM 60 P0602942 TOOL BOX, EMPTY
31 P0602031 GEAR SHAFT 62 P0602943 HEX WRENCH SET (2.5,3,4,5,6MM)
32 P0602032 TIMING BELT 263L (G0602) 63 P0602944 WRENCH SET (8-10, 12-14, 17-19MM)
33 P6001ZZ BALL BEARING 6001ZZ (G0602) 64 P0602945 BOTTLE FOR OIL
34 P0602034 TIMING PULLEY (G0602) 69 P0602069 STANDARD SCREWDRIVER #1
35 PR49M INT RETAINING RING 12MM (G0602) 70 P0602070 PHILLIPS SCREWDRIVER #1
36 P0602036 SPACER
Please Note: We do our best to stock replacement parts whenever possible, but we cannot guarantee that all parts shown here
are available for purchase. Call (800) 523-4777 or visit our online parts store at www.grizzly.com to check for availability.
