-6-
Model G0765 (Mfd. Since 5/15)
The information contained herein is deemed accurate as of 2/21/2018 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
PAGE 1 OF 3
Model G0765
MACHINE DATA
SHEET
Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G0765 7" X 14" VARIABLE‐SPEED BENCHTOP
LATHE
Product Dimensions:
Weight................................................................................................................................................................ 88 lbs.
Width (side-to-side) x Depth (front-to-back) x Height............................................................................. 30 x 9 x 10 in.
Footprint (Length x Width)................................................................................................................. 29-3/4 x 8-1/2 in.
Shipping Dimensions:
Type.......................................................................................................................................................... Wood Crate
Content........................................................................................................................................................... Machine
Weight.............................................................................................................................................................. 110 lbs.
Length x Width x Height....................................................................................................................... 33 x 15 x 15 in.
Must Ship Upright................................................................................................................................................... Yes
Electrical:
Power Requirement........................................................................................................... 110V, Single-Phase, 60 Hz
Full-Load Current Rating........................................................................................................................................ 10A
Minimum Circuit Size.............................................................................................................................................. 15A
Connection Type....................................................................................................................................... Cord & Plug
Power Cord Included.............................................................................................................................................. Yes
Power Cord Length................................................................................................................................................. 6 ft.
Power Cord Gauge......................................................................................................................................... 18 AWG
Plug Included.......................................................................................................................................................... Yes
Included Plug Type.................................................................................................................................... NEMA 5-15
Switch Type........................................................................................... ON/OFF Push Button Switch w/Safety Cover
Motors:
Main
Horsepower............................................................................................................................................. 3/4 HP
Phase............................................................................................................................................ Single-Phase
Amps............................................................................................................................................................ 10A
Speed................................................................................................................................................ 5000 RPM
Type................................................................................................................................. Universal Brush-Type
Power Transfer .................................................................................................................................. Belt Drive
Bearings........................................................................................................... Shielded & Permanently Sealed
Main Specifications:
Operation Info
Swing Over Bed........................................................................................................................................... 7 in.
Distance Between Centers.................................................................................................................. 13-3/4 in.
Swing Over Cross Slide......................................................................................................................... 2-1/8 in.
Swing Over Saddle...................................................................................................................................... 5 in.
Maximum Tool Bit Size........................................................................................................................... 5/16 in.
Compound Travel.................................................................................................................................. 2-3/4 in.
Carriage Travel.................................................................................................................................... 12-1/2 in.
Cross Slide Travel................................................................................................................................. 2-3/4 in.
