Figure 123. H7991 Mini Mag Base Indicator Set.
H7991—Mini Mag Base Indicator Set
Set features a 7 Jewel indicator with 0.0005" reso-
lution. The mini magnetic base measures 1
3
⁄16" x
1
3
⁄16" x 1
3
⁄8" and includes a single lock knob for
easy setups. Includes 2 dovetail tool posts and a
protective plastic case.
order online at www.grizzly.com or call 1-800-523-4777
Figure 122. G9788 4-Pc. Measuring Tool Set.
G9788—4-Pc. Measuring Tool Set
This is the set you need for accurate measure-
ments. Includes a stainless steel 6" dial caliper, a
6" scale with inch scale on one side and a metric
scale on the other, a 1" carbide-tipped microm-
eter with vernier scale, and a 4" precision square
with beveled edge. Comes with molded case and
micrometer adjustment wrench.
SIZE
BODY
DIA.
DRILL
DIA.
OVERALL
LENGTH
1
1
⁄8"
3
⁄64" 1
1
⁄4"
2
3
⁄16"
5
⁄64" 1
7
⁄8"
3
1
⁄4"
7
⁄64"
2"
4
5
⁄16"
1
⁄8" 2
1
⁄8"
Figure 124. HSS ground center-drill sets.
H5930—4-Pc. Center Drill Set 60°
H5931—4-Pc. Center Drill Set 82°
Double-ended HSS Center Drills are precision
ground. Each set includes sizes 1–4.
G9361—Heavy-Duty Triple Bearing Live Center
MT#2
This Triple Bearing Live Center is hardened to
61-65 Rockwell and has a unique head driving
mechanism that prevents dust, chips, and coolant
from entering the internal workings. Made with
precision, high-quality bearings, this live center
has an accuracy of 0.0003".
Figure 121. G9361 MT#2 Live Center.
