-16 -
Model G0925 (Mfd. Since 02/20)
6. Use acetone or lacquer thinner to clean
spindle and chuck mating surfaces.
7. Retract chuck jaws completely into chuck.
Figure 14. Example of using block of wood and
hammer to tap chuck onto spindle taper.
9
. Attempt to separate spindle and chuck by
hand—if they separate, repeat Steps 6–8.
8. Push chuck onto spindle taper, then use
a wood block and hammer or mallet to hit
chuck once with moderate force as shown in
Figure 14.
Note: Hitting chuck directly with a steel ham-
mer may damage chuck, making it unsafe to
use.
5. Thread (3) downfeed handles into downfeed
hub, as shown in Figure 13.
Figure 13. Downfeed handles installed in hub.
Hub
Downfeed
Handle
To Next Page
