-4-
Model G0925 (Mfd. Since 2/20)
16. Attempt to separate spindle and chuck by
hand—if they separate, repeat Steps 13–15.
17
. Thread (3) downfeed handles into downfeed
hub, as shown in Figure 10.
Figure 10. Downfeed handles installed in hub.
Hub
Downfeed
Handle
Figure 9. Using block of wood and hammer to
tap chuck onto spindle taper.
15. Push chuck onto spindle taper, then use
a wood block and hammer or mallet to hit
chuck once with moderate force as shown in
Figure 9.
Note: Hitting chuck directly with a steel ham-
mer may damage chuck, making it unsafe to
use.
