Grizzly G0925 User Manual

Model G0925 (Mfd. Since 02/20)
-35-
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0925001 V-BELT M26 3L260 44 P0925044 SPINDLE
2 P0925002 MOTOR PULLEY 45 P0925045 BALL BEARING 6201Z
3 P0925003 SET SCREW M6-1 X 8 46 P0925046 QUILL
4 P0925004 POWER CORD 18G 3W 72" 5-15P 47 P0925047 BALL BEARING 6201Z
5 P0925005 SET SCREW M6-1 X 8 48 P0925048 EXT RETAINING RING 12MM
6 P0925006 SPINDLE PULLEY 49 P0925049 SPACER 39 X 50 X 2
7 P0925007 PULLEY CAP 50 P0925050 HEX NUT M8-1.5
8 P0925008 KNOB BOLT M5-.8 X 9, D20, ROUND KD 51 P0925051 SET SCREW M8-1.5 X 16
9 P0925009 BELT COVER 52 P0925052 PINION GEAR
10 P0925010 FLAT WASHER 5MM 53 P0925053 LEVER SHAFT-DE M10-1.5 X 12, 8
11 P0925011 ACORN NUT M5-.8 54 P0925054 KNOB M8-1.25, D41
12 P0925012 HEX NUT M5-.8 55 P0925055 FLAT WASHER 6MM
13 P0925013 CORD CLAMP 56 P0925056 PHLP HD SCR M6-1 X 6
14 P0925014 EXT RETAINING RING 21MM 57 P0925057 CHUCK KEY SEAT
15 P0925015 SPINDLE PULLEY SHAFT 58 P0925058 KNOB BOLT M8-1.25 X 12, D33, WING
16 P0925016 INT RETAINING RING 42MM 59 P0925059 COMPRESSION SPRING 0.8 X 11 X 24
17 P0925017 BALL BEARING 6203ZZ 60 P0925060 BELT TENSION SHAFT
18 P0925018 FLAT WASHER 5MM 61 P0925061 BELT TENSION SHAFT CAP
19 P0925019 PHLP HD SCR M5-.8 X 12 62 P0925062 HEADSTOCK
20 P0925020 PHLP HD SCR M6-1 X 8 63 P0925063 SET SCREW M8-1.25 X 8
21 P0925021 FLAT WASHER 6MM 64 P0925064 LOCK NUT M8-1
22 P0925022 FLAT WASHER 9MM RUBBER 65 P0925065 FLAT WASHER 8MM
23 P0925023 GASKET 15 X 26 X 10MM 66 P0925066 HEX BOLT M8-1 X 25
24 P0925024 HEX NUT M10-1.5 67 P0925067 MOTOR 1/3HP 120V 1-PH
25 P0925025 RETURN SPRING COVER 67-1 P0925067-1 MOTOR FAN COVER
26 P0925026 FLAT COIL SPRING 67-2 P0925067-2 MOTOR FAN
27 P0925027 TAP SCREW M3 X 10 67-3 P0925067-3 R CAPACITOR 22M 250V 5/16 X 2-1/2
28 P0925028 PADDLE SWITCH W/KEY DKLD AN17 20A 125V 67-4 P0925067-4 CAPACITOR COVER
29 P0925029 SWITCH PLATE 67-5 P0925067-5 BALL BEARING 6202Z FRONT
30 P0925030 SWITCH BOX 67-6 P0925067-6 BALL BEARING 6201Z REAR
31 P0925031 BELLEVILLE LOCK WASHER 8MM 68 P0925068 FOLDING HANDLE 115L, M10-1.5 X 25
32 P0925032 LOCK WASHER 8MM 69 P0925069 TABLE TILT SCALE
33 P0925033 PHLP HD SCR M5-.8 X 8 70 P0925070 TABLE CLAMPING BRACKET
34 P0925034 PHLP HD SCR M5-.8 X 10 71 P0925071 TABLE
35 P0925035 DEPTH SCALE 72 P0925072 HEX BOLT M12-1.75 X 30
36 P0925036 POINTER 73 P0925073 COLUMN
37 P0925037 HEX NUT M10-1.5 74 P0925074 HEX BOLT M8-1.25 X 20
38 P0925038 THREADED DEPTH ROD 75 P0925075 COLUMN SEAT
39 P0925039 HEX NUT M6-1 76 P0925076 BASE
40 P0925040 DEPTH STOP BRACKET 77 P0925077 HEX WRENCH 4MM
41 P0925041 HEX NUT M5-.8 78 P0925078 DRILL CHUCK KEY 3MM STD-SE 12T SD 13MM
42 P0925042 PHLP HD SCR M5-.8 X 25 79 P0925079 LOCK WASHER 12MM
43 P0925043 DRILL CHUCK JT33 X 1.5-13MM 80 P0925080 LOCK WASHER 5MM
Main Parts List
