G1014Z Combination Sander -17-
Curved Sanding
To sand curves, use the end of the belt arm. Hold
the workpiece firmly and apply light, even pres-
sure to the belt. To avoid excessive loading of the
belt in one area, move workpiece slowly across
entire surface of belt. Figure 21.
Figure 21.
Disc Sanding
1. Loosen table lock knob and tilt work table to
desired angle. Tighten lock knob.
2. Ease workpiece into the half of the disc that
spins down toward the table. Figure 22.
3. When using the table for beveled sanding
operations, smaller workpieces are at risk of
getting jammed between the disc (or vertical
belt) and the table. Figure 23.
Figure 22.
Figure 23.
