Model G0794 (Mfd. Since 05/18)
-9-
Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0794001 BASE 55 P0794055 MOTOR MOUNTING PLATE
2 P0794002 HEX BOLT M10-1.5 x 35 56 P0794056 FLAT WASHER 12MM
3 P0794003 LONG RACK 57 P0794057 HEX NUT M12-1.75
4 P0794004 COLUMN W/COLUMN HOLDER 58 P0794058 MOTOR 3/4HP 110V 1-PH
5 P0794005 TABLE BRACKET 58-1 P0794058-1 CAPACITOR COVER
6 P0794006 HANDLE 58-2 P0794058-2 MOTOR JUNCTION BOX
7 P0794007 SET SCREW M6-1 X 10 58-3 P0794058-3 MOTOR FAN COVER
8 P0794008 SHAFT 58-4 P0794058-4 MOTOR FAN
9 P0794009 STUD-SE M6-1 X 12, 17 58-6 P0794058-6 S CAPACITOR 200M 125V
10 P0794010 HEX NUT M6-1 58-7 P0794058-7 CENTRIFUGAL SWITCH
11 P0794011 FLAT WASHER 16MM 58-8 P0794058-8 CONTACT PLATE
12 P0794012 HEX BOLT M16-2 X 40 58-9 P0794058-9 BALL BEARING 6203ZZ
13 P0794013 SWIVEL LOCK HANDLE M10-1.5 X 30 58-10 P0794058-10 BALL BEARING 6203ZZ
14 P0794014 TABLE ARM BRACKET 58-11V2 P0794058-11V2 TERMINAL BLOCK 3P V2.05.18
15 P0794015 TABLE 59 P0794059 MOTOR PULLEY
16 P0794016 SWIVEL LOCK HANDLE M12-1.75 X 50 60 P0794060 KEY 5 X 5 X 25
17 P0794017 GEAR 10T 61 P0794061 SET SCREW M6-1 X 10
18 P0794018 WORM GEAR 62 P0794062 V-BELT M24
19 P0794019 RACK RING 63 P0794063 CENTER SHAFT
20 P0794020 STOP PIN 64 P0794064 BALL BEARING 6202ZZ
21 P0794021 SET SCREW M6-1 X 10 65 P0794065 BALL BEARING 6202ZZ
22 P0794022 FEED SHAFT 66 P0794066 EXT RETAINING RING 15MM
23 P0794023 DEPTH RING 67 P0794067 CENTER PULLEY
24 P0794024 ROLL PIN 5 X 40 68 P0794068 FLAT WASHER 6MM
25 P0794025 DOWNFEED HANDWHEEL HUB 69 P0794069 PHLP HD SCR M6-1 X 10
26 P0794026 DOWNFEED HANDLE M12-1.75 MALE 70 P0794070 PHLP HD SCR M5-.8 X 10
27 P0794027 DOWNFEED KNOB M12-1.75 FEMALE 71 P0794071 FLAT WASHER 5MM
28 P0794028 LOCK WASHER 12MM 72 P0794072 PULLEY COVER KNOB M5-.8
29 P0794029 KNOB BOLT M8-1.25 X 22 73 P0794073 PULLEY COVER
30 P0794030 SET SCREW M10-1.5 X 12 74 P0794074 V-BELT M25
32 P0794032 EXT RETAINING RING 16MM 75 P0794075 PULLEY NUT
33 P0794033 BELT TENSION LEVER 76 P0794076 SPINDLE PULLEY
34 P0794034 KNOB BOLT M10-1.5 X 25 77 P0794077 PULLEY SHAFT
35 P0794035 HEX BOLT M8-1.25 X 30 78 P0794078 INT RETAINING RING 52MM
36 P0794036 FLAT WASHER 8MM 79 P0794079 BALL BEARING 6205ZZ
37 P0794037 HEX NUT M8-1.25 80 P0794080 SPACER
38 P0794038 HEX NUT M10-1.5 81 P0794081 BALL BEARING 6205ZZ
39 P0794039 SET SCREW M10-1.5 X 30 82 P0794082 INT RETAINING RING 25MM
40 P0794040 HEX NUT M12-1.5 83 P0794083 ROUND NUT M17-1
41 P0794041 HEX NUT M12-1.5 84 P0794084 TAB WASHER
42 P0794042 RETURN SPRING COVER 85 P0794085 BALL BEARING 6203ZZ
43 P0794043 COILED RETURN SPRING 86 P0794086 RUBBER WASHER 62 X 50 X 2
44 P0794044 RETURN SPRING PLATE 87 P0794087 QUILL
45 P0794045 SWITCH/DRO HOUSING 88 P0794088 BALL BEARING 6205ZZ
46 P0794046 PHLP HD SCR M5-.8 X 14 89 P0794089 SPINDLE
48 P0794048 PHLP HD SCR M5-.8 X 10 90 P0794090 DRILL CHUCK ARBOR MT2/JT33
49 P0794049 CORD CLAMP 91 P0794091 DRILL CHUCK 5/8" X JT33 W/KEY
50 P0794050 HEADSTOCK CASTING 92 P0794092 CHUCK KEY 5/16" TH-SE 11T SD-5/8"
51 P0794051 HEX BOLT M8-1.25 X 16 97 P0794097 LASER SWITCH KCD1-101 2/8A 250VAC
52 P0794052 SHIFTER 98 P0794098 GRIZZLY SAFETY PADDLE SWITCH
53 P0794053 MOTOR MOUNT SLIDE BAR (SOLID) 99 P0794099 INT RETAINING RING 35MM
54 P0794054 MOTOR MOUNT SLIDE BAR (GROOVED) 100 P0794100 POWER CORD 18G 3W 73" 5-15P
