-12-
G9729 Combination Lathe/Mill
Inventory
After all the parts have been removed from the
two boxes, you should have the following items:
Box 1: (Figure 3) Q
ty
A.
Model G9729 Combo Lathe/Mill ................. 1
B.
Face Plate .................................................. 1
C.
Adaptor Plate .............................................. 1
Small Box
Contents:
D. 120T/127T Combo Gear, & 72T Gear ....... 1
E.
36T Gear, & 33T Gear ............................... 1
F. 30T Gear, & 27T Gear ............................... 1
G
. 60T Gear, & 48T Gear ............................... 1
H
. 42T
Gear, & 39T Gear ............................... 1
I. Plastic Spindle Cover ................................. 1
J. Lathe Chuck Jaws ...................................... 1
K. Leadscrew Crank Handle ........................... 1
L. Wrench 13/16mm
...................................... 1
Flat Head Screwdriver ................................ 1
Drift ............................................................. 1
Hex Wrench 3, 4, 5, & 8mm ....................... 4
M
. MT#4 Dead Center ..................................... 1
N
. MT#3
Dead Center ..................................... 1
O. Lathe Chuck Key ........................................ 1
Tool Post Wrench ....................................... 1
Shims ......................................................... 3
Drill Chuck Key ........................................... 1
Item
not shown:
P. Hex Handle 14mm for Head Lock .............. 1
Figure 3. Model G9729 Inventory.
In the event that any nonproprietary parts are
missing (e.g. a nut or a washer), we would be
glad to replace them, or for the sake of expedi-
en
cy, replacements can be obtained at your local
hardware store.
