G9729 Combination Lathe/Mill
-63-
G9729 Parts Breakdown 300 Series
REF PART # DESCRIPTION REF PART # DESCRIPTION
301 P9729301 STRAIN RELIEF 1/2" SNAP IN 319 P9729319 ELECTRICAL PLATE
302 PS56M PHLP HD SCR M4-.7 X 16 320 PS38M PHLP HD SCR M4-.7 X 10
303 PS07M PHLP HD SCR M4-.7 X 8 321 P9729321 PIVOT
304 P9729304 ELECTRIC BOX 322 P9729322 STRAIGHT PIN 2 X 12MM
306 P9729306 ELECTRIC HOUSING 323 P9729323 COMPRESSION SPRING
307 P9729307 PULLEY BOX 325 PRP37M ROLL PIN 3 X 14
308 P9729308 MICRO SWITCH 326 P9729326 LATCH PIECE
309 P9729309 STRAIN RELIEF 1/2" SNAP IN 327 PFH41M FLAT HD SCR M4-.7 X 16
310 PS18M PHLP HD SCR M4-.7 X 25 328 P9729328 MICRO SWITCH LEVER
311 P9729311 ELECTRICAL PANEL 329 PN06M HEX NUT M5-.8
312 P9729312 CONTACTOR LC1 D1201 330 P9729330 DOOR
313 P9729313 KILL SWITCH 331 PS82M PHLP HD SCR M5-.8 X 35
313A P9729313A E- STOP KNOB 332 P9729332 STUD
314A P9729314A START SWITCH 333 P9729333 KNOB M8-1.25
315 P9729315 WIRE BLOCK 334 P9729334 CHART
316 PS38M PHLP HD SCR M4-.7 X 10 337 P9729337 LENSE
317 P9729317 LIGHT INDICATOR 339 P9729339 START BUTTON
317-1 P9729317-1 INDICATOR BULB 340 P9729340 PLUG NEMA 5-15
318A P9729318A FOR/REV SWITCH ASSY
