G9729 Combination Lathe/Mill
-31-
Figure 29. Carriage lock.
The carriage lock lever is located under the right
hand side of the apron as shown in Figure 29.
This
allows the carriage to be locked in place for
precision facing operations while using the lathe
or to make a set up in a milling operation more
rigid.
Carriage Lock
