G9729 Parts Breakdown 900 Series
REF PART # DESCRIPTION REF PART # DESCRIPTION
901 P9729901 TAILSTOCK 921 P9729921 STUD M10-1.5 X 40
902 P9729902 T-KEY 922 P9729922 SPACER
903 P9729903 TAILSTOCK NUT 923 P9729923 HANDLE HUB
904 P9729904 TAILSTOCK BARREL 924 P9729924 HANDLE
905 PSS52M SET SCREW M4-.7 X 8 925 P9729925 HANDLE KNOB M10-1.5
906 P9729906 TAILSTOCK SCREW 926 P9249002 OILER 6
907 PK05M KEY 4 X 4 X 10 927 PSS39M SET SCREW M10-1.5 X 50
908 P9729908 SPACER 928 P9729928 LOCATING KEY
909 PRP35M ROLL PIN 5 X 10 929 PFH37M FLAT HD SCR M5-.8 X 25
912 P9729912 DIAL 930 PW04M FLAT WASHER 10MM
913 P9729913 DIAL SEAT 931 PB31M HEX BOLT M10-1.5 X 40
914 P9729914 SPRING PIECE 933 P9729933 QUILL SCALE
915 P9729915 HANDWHEEL 12 X 100 934 P9729934 RIVET
916 PW04M FLAT WASHER 10MM 935 P9729935 LABEL
917 P9729917 ACORN NUT M10-1.5 936 P9729936 CARRIAGE SCALE
918 P9729918 HANDLE 937 P9729937 HANDLE SCREW M8-1.25 X 55
919 P9729919 LOCKING PAD (LOWER) 938 P9729938 SCALE POINTER
920 P9729920 LOCKING PAD (UPPER)
