Grizzly H2933 - MACHINE DATA SHEET (G0447)

-8- H2933/H2934/G0447/G0581 Wide Belt Sander
Design Type ........................................................................................................................Floor Model
Overall Dimensions:
Overall Height W/Dust Ports .................................................................................................... 79"
Overall Height W/O Dust Ports .................................................................................................73"
Overall Width ..........................................................................................................................53
1
⁄2"
Overall Depth .........................................................................................................................59
1
⁄2"
Conveyor Height at Lowest Setting ...........................................................................................32''
Net Weight ....................................................................................................................... 3197 lbs.
Shipping Weight .............................................................................................................. 3637 lbs.
Footprint .......................................................................................................................... 52" x 31"
Capacities:
Maximum Board Width ...........................................................................................................36
1
⁄2"
Maximum Board Thickness .........................................................................................................6"
Minimum Board Length .............................................................................................................11"
Minimum Board Thickness .........................................................................................................
1
⁄4"
Drum Speed (Front) ...................................................................................................... 3543 FPM
Drum Speed (Rear) ....................................................................................................... 2554 FPM
Conveyor Speed ........................................................................................................... 17-63 FPM
Dust Ports ............................................................................................................................ Six, 4''
Drum Diamiter .......................................................................................... (Front 7.87"), (Rear 4")
Sanding Drum Motor:
Type ......................................................................................................................TEFC Induction
Horsepower .......................................................................................................................... 20 HP
Voltage / Phase / Cycle ........................................................... 220V / 440V Three-Phase ⁄ 60 HZ
Amps ................................................................................................................................ 50 / 25A
RPM ..............................................................................................................................1725 RPM
Power Transfer to Drums ........................................................................................... Triple V-Belt
Conveyor Feed Motor:
Type ......................................................................................................................TEFC Induction
Horsepower ............................................................................................................................ 1 HP
Voltage / Phase / Cycle ........................................................... 220V / 440V Three-Phase ⁄ 60 HZ
Amps .............................................................................................................................. 3.4 / 1.7A
RPM ..............................................................................................................................1725 RPM
Power Transfer ........................................................................................... Twin and Triple V-Belt
Table Lift Motor:
Type ......................................................................................................................TEFC Induction
Horsepower ......................................................................................................................... 1⁄4 HP
Voltage / Phase / Cycle ........................................................... 220V / 440V Three-Phase ⁄ 60 HZ
Amps .............................................................................................................................. 1.2 / 0.6A
RPM ..............................................................................................................................1725 RPM
Power Transfer ..................................................................................................................... V-Belt
General Construction:
Cabinet ...................................................................................................................................Steel
Operating Air Pressure ........................................................................................................ 75 PSI
Sanding Belt Oscillation ................................................................................................ Adjustable
Emergency Sanding Belt Brake .............................................................................. Air Disc Brake
Control Panel ................................................. Push Button Motor Controls, and Amp Load Meter
Sanding Belt .................................................................................................................... 37" x 75"
Graphite Size ............................................................................................................... 37.8" x 3.5"
Sanding Type ..............................................................................................................Platen Style
Specifications, while deemed accurate, are not guaranteed.
MODEL G0447 37" DOUBLE-HEAD
TALL WIDE-BELT SANDER
Customer Service #: (570) 546-9663 • To Order Call: (800) 523-4777 • Fax #: (800) 438-5901
MACHINE DATA
SHEET
Machine Data Sheet (G0447)
