Grizzly H2933 - Table Lift System Parts List

H2933/H2934/G0447/G0581 Wide Belt Sander -61-
Table Lift System Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
101 PH29332101
ELEVATION SCREW
318 PH29332318
LOCK WASHER 5/16
102 PH29332102
HEX BOLT 5/16-18 X 1
319 PH29332319
HEX BOLT 5/16-18 X 3/4
103 PH29332103
FLAT WASHER 5/16
320 PH29332320
SET SCREW 1/4-20 X 1/2
104 PH29332104
LOCK WASHER 5/16
321 PH29332321
HAND WHEEL
105 PH29332105
LOCK WASHER 3/8
322 PH29332322
MOTOR BASE
106 PH29332106
HEX BOLT 3/8-16 X 1
323 PH29332323
HEX BOLT 1/4-20 X 1
107 PH29332107
ELEVATION SLIDE
324 PH29332324
LOCK WASHER 1/4
108 PH29332108
DUST BOOT
325 PH29332325
ADJUSTMENT ROD
109 PH29332109
HEX BOLT 5/16-18 X 3/4
326 PH29332326
FLAT WASHER 1/2
110 PH29332110
LOCK WASHER 5/16
327 PH29332327
HEX NUT 1/2-12
111 PH29332111
CHAIN (H2933)
328 PH29332328
LOCK WASHER 1/2
111 PH29342111
CHAIN (H2934/G0447)
111 P05812111
CHAIN (G0581)
201 PH29332201
NUT HOUSING
331-1 PH29332331-1
FAN COVER (ALL MODELS)
202 PH29332202
NUT
331-2 PH29332331-2
FAN (ALL MODELS)
203 PH29332203
THRUST BEARING 51107
332 PH29332332
HEX NUT 1/4-20
204 PH29332204
EXT RETAINING RING 35MM
333 PH29332333
HEX BOLT 1/2-12 X 4-1/2
206 PH29332206
SPROCKET WHEEL
334 PH29332334
PROXIMITY SWITCH PLATE
301 PH29332301
ELEVATION GEAR BOX
335 PH29332335
HEX BOLT 1/4-20 X 1/2
302 PH29332302
WORM GEAR
336 PH29332336
PROXIMITY SWITCH
303 PH29332303
BALL BEARING 6005ZZ
337 PH29332337
SPECIAL SCREW M3-.5 X 40
304 PH29332304
BEARING CAP
338 PH29332338
HEX NUT M3-.5
305 PH29332305
CAP SCREW 1/4-20 X 3/4
339 PH29332339
KEY 5/16 X 5/16 X 3/4
306 PH29332306
WORM SHAFT
340 PH29332340
KEY 4 X 4 X 20
307 PH29332307
BALL BEARING 6002ZZ
341 PH29332341
KEY 4 X 4 X 16
308 PH29332308
BEARING CAP
401 PH29332401
SPROCKET WHEEL ADJUSTOR
309 PH29332309
CAP SCREW 10-24 x 3/4
402 PH29332402
SPROCKET WHEEL SHAFT
310 PH29332310
BEARING CAP
403 PH29332403
BALL BEARING 6003ZZ
311 PH29332311
CAP SCREW 1/4-20 X 5/8
404 PH29332404
ADJUSTMENT SPROCKET
312 PH29332312
SPROCKET WHEEL
405 PH29332405
ADJUSTMENT ROD
313 PH29332313
SET SCREW 1/4-20 X 1/2
406 PH29332406
FLAT WASHER 3/8
314 PH29332314
PULLEY
407 PH29332407
HEX NUT 3/8-16
315 PH29332315
V-BELT A-36 4L360
408 PH29332408
HEX NUT 5/16-18
316 PH29332316
PULLEY
409 PH29332409
LOCK WASHER 5/16
317 PH29332317
SET SCREW 1/4-20 X 1/2
410 PH29332410
HEX BOLT 5/16-18 X 3/4
MOTOR 1/4HP 220V/440V 3PH (ALL
MODELS)
PH293323331
331
