Grizzly H2933 - Sanding Motor System Parts List

H2933/H2934/G0447/G0581 Wide Belt Sander -59-
Sanding Motor System Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
101 PH29331101
MACHINE FRAME (H2933)
118 PH29341118
PULLEY BUSHING (H2934/G0447)
101 PH29341101
MACHINE FRAME (H2934/G0447)
118 P05811118
PULLEY BUSHING (G0581)
101 P05811101
MACHINE FRAME (G0581)
119 PH29331119
V-BELT A-50 4L500
102 PH29331102
MOTOR BASE (H2933)
121 PH29331121
BRAKE BRACKET
102 PH29341102
MOTOR BASE (H2934/G0447)
122 PH29331122
FLAT WASHER 3/8
102 P05811102
MOTOR BASE (G0581)
123 PH29331123
HEX BOLT 3/8-16 X 3/4
103 PH29331103
MOTOR BASE HINGE (H2933)
124 PH29331124
FLAT HEAD NUT
125 PH29331125
CAP SCREW 1/4-20 X 3/4
126 PH29331126
LIMIT SWITCH
103 P05811103
MOTOR BASE HINGE (G0581)
127 PH29331127
LIMIT SWITCH PLATE
104 PH29331104
HEX NUT 1/2-12
128 PH29331128
HEX BOLT 1/4-20 X 1/2
105 PH29331105
MOTOR BASE ADJUSTMENT ROD
129 PH29331129
FLAT WASHER 1/4
106 PH29331106
LOCK WASHER 1/2
132 PH29331132
FLAT HD SCR M6-1 X 25
107 PH29331107
HEX BOLT 1/2-12 X 1-1/2
133 PH29331133
LOCK WASHER 1/4
108 PH29331108
FLAT WASHER 1/2
201 PH29331201
IDLE WHEEL ADJ BRACKET
202 PH29331202
LOCK WASHER 3/4
203 PH29331203
HEX NUT 1/2-12
205 PH29331205
HEX BOLT 3/8-16 X 3-1/2
206 PH29331206
HEX NUT 3/8-16
208 PH29331208
IDLE WHEEL SHAFT
209 PH29331209
BALL BEARING 6305ZZ
109-1 PH29331109-1
MOTOR FAN (H2933)
210 PH29331210
PULLEY
109-1 PH29341109-1
MOTOR FAN (H2934/G0447)
211 PH29331211
BALL BEARING 6206ZZ
109-1 P05811109-1
MOTOR FAN (G0581)
212 PH29331212
EXT RETAINING RING 25MM
109-2 PH29331109-2
MOTOR FAN COVER (H2933)
213 PH29331213
V-BELT A-40 4L400
301 PH29331301
BRAKE BRACKET
301-1 PH29331301-1
BREAK BRACKET FRONT GUARD
109-2 P05811109-2
MOTOR FAN COVER (G0581)
302 PH29331302
BRAKE LINING SET
110 PH29331110
PULLEY (H2933)
303 PH29331303
BRAKE ARBOR
110 PH29341110
PULLEY (H2934/G0447)
304 PH29331304
BRAKE COMPRESSION SPRING
110 P05811110
PULLEY (G0581)
305 PH29331305
BRAKE INSIDE PIECE
111 PH29331111
CAP SCREW 5/16-18 X 1-1/4
306 PH29331306
FLAT HD SCR 1/4-20 X 5/8
112 PH29331112
LOCK WASHER 5/16
307 PH29331307
BRAKE PIN
113 PH29331113
KEY 12 X 8 X105
308 PH29331308
CAP SCREW 10-24 X 5/8
114 PH29331114
HEX BOLT 5/16-18 X 1
310 PH29331310
LOCK WASHER 3/8
115 PH29331115
LOCK WASHER 5/16
311 PH29331311
HEX NUT 3/8-16
116 PH29331116
ROTOR
312 PH29331312
CAP SCREW 1/4-20 X 1/2
117 PH29331117
V-BELT B-76 5L760
313 PH29331313
BRAKE GASKET
118 PH29331118
PULLEY BUSHING (H2933)
MOTOR 15HP 220V/440V 3PH
(H2933)
PH29331109
109
109
109
PH29341109
P05811109
MOTOR FAN COVER (H2934/G0447)
PH29341109-2
109-2
MOTOR BASE HINGE
(H2934/G0447)
PH29341103
103
MOTOR 20HP 220V/440V 3PH
(H2934/G0447)
MOTOR 25HP 220V/440V 3PH
(G0581)
