Grizzly H2933 - Conveyor System Parts List

H2933/H2934/G0447/G0581 Wide Belt Sander -63-
Conveyor System Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
101 PH29333101
CONVEYOR TABLE (H2933)
123-1 P05813123-1
MOTOR FAN COVER (G0581)
101 P05813101
CONVEYOR TABLE (G0581)
123-2 P05813123-2
MOTOR FAN (G0581)
102 PH29333102
CONVEYOR BELT (H2933)
124 PH29333124
LOCK WASHER 5/8
102 PH29343102
CONVEYOR BELT (H2934/G0447)
126 PH29333126
TIMING BELT 1422V-290
102 P05813102
CONVEYOR BELT (G0581)
127 PH29333127
CAP SCREW M10-1.5 X 25
103 PH29333103
REDUCER FIX PLATE
128 PH29333128
BASE PLATE
104 PH29333104
CUSHION
129 PH29333129
VARIABLE SPEED UNIT COVER
105 PH29333105
LOCK WASHER 3/8
130 PH29333130
HEX BOLT M8-1.25 X 20
106 PH29333106
HEX BOLT 3/8-16 X 1
131 PH29333131
INFEED ROLLER BRACKET
107 PH29333107
OUTFEED ROLLER (H2933)
132 PH29333132
CAP SCREW 10-24 x 3/4
133 PH29333133
INFEED ROLLER BRACKET
135 PH29333135
CONVEYOR POSITION WHEEL
107 P05813107
OUTFEED ROLLER (G0581)
136 PH29333136
CAP SCREW 5/16-18 X 2
108 PH29333108
BEARING UCF206
137 PH29333137
LOCK WASHER 5/16
109 PH29333109
GEARBOX
138 PH29333138
HEX NUT 5/16-18
110 PH29333110
BREATHER
111 PH29333111
PLUG
112 PH29333112
BALL BEARING UCF205
113 PH29333113
LOCK WASHER 3/8
114 PH29333114
HEX BOLT 3/8-16 X 1-1/4
115 PH29333115
BEARING CAP
116 PH29333116
DRIVEN PULLEY
141 PH29333141
PHLP HD SCR 1/4-20 X 1/2
117 PH29333117
HEX BOLT 3/8-16 X 1-1/2
142 PH29333142
LIMIT SWITCH
118 PH29333118
DRIVING PULLEY
143 PH29333143
PHLP HD SCR 10-24 x 1 1/2
119 PH29333119
KEY 7 X 7 X 55
144 PH29333144
HEX BOLT 1/2-12 X 3
120 PH29333120
HEX BOLT M8-1.25 X 25
201 PH29333201
INFEED ROLLER SHAFT
121 PH29333121
LOCK WASHER 8MM
202 PH29333202
INFEED ROLLER (H2933)
202 PH29343202
INFEED ROLLER (H2934/G0447)
202 P05813202
INFEED ROLLER (G0581)
203 PH29333203
BALL BEARING 6206ZZ
204 PH29333204
EXT RETAINING RING 30MM
205 PH29333205
ELEVATION LIMITER
206 PH29333206
CAP SCREW 1/4-20 X 1-1/2
CONVEYOR TABLE
(H2934/G0447)
PH29343101101 123-2
MOTOR FAN (H2933, H2934,
G0447)
PH29333123-2
OUTFEED ROLLER
(H2934/G0447)
PH29343107107
123 PH29333123
MOTOR 1HP 220V/440V 3PH
(H2933, H2934, G0447)
123 P05813123
MOTOR 2HP 220V/440V 3PH
(G0581)
123-1 PH29333123-1
MOTOR FAN COVER (H2933,
H2934, G0447)
EMGNCY BRAKE PUSH-PLATE
(G0581)
EMGNCY BRAKE PUSH-PLATE
(H2934/G0447)
EMGNCY BRAKE PUSH-PLATE
(H2933)
PH29333140140
140 PH29343140
P05813140140
