H2933/H2934/G0447/G0581 Wide Belt Sander -71-
Cabinet Assembly Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
101 PH29337101
UPPER FRAME COVER (H2933)
101 PH29347101
UPPER FRAME COVER (H2934)
101 P04477101
UPPER FRAME COVER (G0447)
101 P05817101
UPPER FRAME COVER (G0581)
102 PH29337102
DUST PORT 4"
103 PH29337103
PHLP HD SCR M6-1 X 12
104 PH29337104
LEFT ACCESS PANEL (H2933)
104 PH29347104
LEFT ACCESS PANEL (H2934)
104 P04477104
LEFT ACCESS PANEL (G0447)
104 P05817104
LEFT ACCESS PANEL (G0581)
105 PH29337105
RIGHT ACCESS PANEL (H2933)
110 PH29337110
FLAT HD SCR 1/4-20 X 1/2
105 PH29347105
RIGHT ACCESS PANEL (H2934)
105 P04477105
RIGHT ACCESS PANEL (G0447)
105 P05817105
RIGHT ACCESS PANEL (G0581)
106 PH29337106
DOOR LOCK
107 PH29337107
HEX BOLT 5/16-18 X 3/4
108 PH29337108
FLAT WASHER 5/16
112 PH29337112
FLAT WASHER 1/4
113 PH29337113
PHLP HD SCR M6-1 X 12
114 PH29337114
HEX BOLT 1/4-20 X 3/4
115 PH29337115
STANDOFF BRACKET
109
P04477109
RIGHT DOOR, LOWER FRAME
(G0447)
109
PH29347109
RIGHT DOOR, LOWER FRAME
(H2934)
RIGHT DOOR, LOWER FRAME
(H2933)
PH29337109
109
109
P05817109
RIGHT DOOR, LOWER FRAME
(G0581)
LEFT DOOR, LOWER FRAME (H2933)
LEFT DOOR, LOWER FRAME (H2934)
LEFT DOOR, LOWER FRAME
(G0447)
LEFT DOOR, LOWER FRAME
(G0581)
P05817109-1
P04477109-1
PH29347109-1
PH29337109-1
109-1
109-1
109-1
109-1
111
PH29337111
FRONT PROTECTION PLATE (H2933)
FRONT PROTECTION PLATE (H2934)
PH29347111
111
111
111
P04477111
P05817111
FRONT PROTECTION PLATE
(G0447)
FRONT PROTECTION PLATE
(G0581)
