OM-BPM-G
Gas Piping Assemblies Parts List
GAS PIPING ASSEMBLIES
KEY QTY PART NO#
1 2 U BOLT 3/4 PIPE N87786
2 5 WASHER PLAIN 1/4 005472
3 5 NUT HEXAGON KEPS 1/4-20 WITH 012940
4 1 ELBOW 90 DEG 1/2 NPT 008747
5 1 NIPPLE 1/2 NPT X 11 005673
6 1 IGNITION MODULE PLATE ASSY-ELECTRONIC IGNITION 160775
7 1 SWIVEL JOINT 1/2 NPT (GAS) 076680
8 2 UNION ELBOW 141354
9 1 TEE 1/2 NPT 008772
10 1 NIPPLE 1/2 NPT X 3.5 009816
11 1 COUPLING FULL 1/2 NPT 005722
12 1 NIPPLE 1/2 NPT X 10 005558
13 1 REAR RADIATION HEAT SHIELD 146145
14 1 IGNITION MODULE COVER 146146
15 2 SCREW ROUND HEAD MACHINE 069788
16 1 NIPPLE 1/2 NPT X 12 005600
17 1 VALVE GAS MANUAL SHUTOFF 1/2 098458
18 1 CONNECTOR MALE 1/2 049429
19 1 FITTIN
G COMPRESSION 90 004584
20 1 TUBE, IGNITION SUPPLY TUBE, 1/4 (NOT SHOWN) 146119
21 1 PILOT SUPPLY TUBE, 1/4 (NOT SHOWN) 146118
23 1 GROMMET 7/8" (NOT SHOWN) 007400
24 1 SPARK IGNITION MODULE-ELECTRONIC IGNITION ONLY 144150
25 1 GAS CONTROL VALVE-ELECTRONIC IGNITION-NATURAL GAS 160776
25 1 GAS CONTROL VALVE-ELECTRONIC IGNITION-PROPANE 160796
26 1 HIGH LIMIT THERMOSTAT (GAS) 119464
27 1 ELBOW FEMALE 90 DEG (NOT SHOWN) 050500
28 1 CONNECTOR, 1/2” RP (BSPT) 116392
