Cover and Counterbalance Assemblies Parts List
Key Qty COVER & COUNTERBALANCE ASSEMBLIES Part #
1 1 COVER ASSEMBLY, 30 GALLON 160861
1 1 COVER ASSEMBLY, 40 GALLON 160808
145480
144790
2 1 COUNTERBALANCE ASSEMBLY, 30 GALLON
2 1 COUNTERBALANCE ASSEMBLY, 40 GALLON
3 4 STUD WELD, 1/4"-20 X 1-1/4" 012589
4 4 WASHER, LOCK 3/8" 005618
5 4 SCREW, HEX HEAD CAP 3/8"-16 X 1" 005612
6 4 NUT, HEX 3/8"-16 005619
7 4 DOME NUTS, 1/4-20 090567
8 2 SCREW, TRUSS HEAD, #10-32 X 3/8" 004173
