Model 613-VS2-LES, Log End Slicer Setup
R-1176866 613-VS2-LES_CJL20160114.doc: 1/15/2016 4:21 PM Grote Company 20
Feed Belt removal
With the tunnel guard opened, pivot up the noses of the two sections of the feed belt. This will
remove tension on the belt. Remove the wing bolts on the side of the conveyor oposit the drive
motor. Slip the belts between the conveyor bed and the standoff holding the conveyor bed.
Injection Belt tensioning
After sanitation is complete and the machine is dry, the belts must to be placed into the correct spots
relative to the drive and idle pulley crowns. Start with the tunnel guard open. Verify that each belt is
placed over a crown on the drive and idle pulley. The pivot nose will pivot down when air, power and
the release latch switch is set to latch.
Injection Belt removal
First, separate the autoload system from the 613 and open the tunnel guard. The counterweight
assembly captures the belts on the injection conveyor. Remove air from the system and use tools to
unbolt the counterweight assembly. Then, remove the two wing bolts on the side of the conveyor
opposite of the drive motor. Gently, lift the conveyor bed to allow the belts to be slipped between the
conveyor bed and the stand off it is mounted to.
Injection Belt tracking
The belts will require no tracking adjustment if they are properly aligned to their correct crown on the
drive and idle pulley. If the belts are not tracking properly, check that they are not twisted or tangled
below the conveyor bed and that they are aligned with the proper crown.
CARRYOUT CONVEYOR SYSTEM
The carryout conveyor system moves product slices out of the machine to the desired customer
location. It consists of a small motor permanently mounted to the slicer and a removable roller bed
and belt assembly. The motor has a storage location on the slicer.
Belt Removal and Installation
Removal
1. Move the Motor to storage location on slicer and secure.
2. Remove Roller Bed and Belt Assembly from slicer.
3. Remove the Tensioning Roller by loosening the two thumbscrews and dropping the roller
assembly out of the frame.
4. The Conveyor Belt has enough slack to then slide off the frame side rail.
Installation and Direction of Travel
Installation is opposite of removal. Ensure the belt spiral leads the crimped connector to which it is
welded.
