4.2.2 LCD Setting
After pressing and holding ENTER button for 3 seconds, the unit will enter setting mode. Press “UP” or “DOWN”
button to select setting programs. Then press “ENTER” button to confirm the selection or ESC button to exit.
Output source priority: To
configure load power
source priority
Solar energy provides power to the loads as first priority.
If solar energy is not sufficient to power all connected loads, battery energy
will supply power the loads at the same time.
Utility provides power to the loads only when any one condition happens:
-
Solar energy is not available
-
Battery voltage drops to either low-level warning voltage or the setting
point in program 12.
Utility will provide power to the loads as first priority.
Solar and battery energy will provide power to the loads only when
utility power is not available.
Solar energy provides power to the loads as first priority.
If solar energy is not sufficient to power all connected loads, battery will
supply power to the loads at the same time.
Utility provides power to the loads only when battery voltage drops to
either low-level warning voltage or the setting point in program 12.
Maximum charging current:
set total charging current for
solar and utility chargers.
(Max. charging current =
utility charging current +
solar charging current)
48V model: default 60A, 10A~80A Settable
(If Li is selected in program 5, this program can’t be set up)
Appliance (default)
If selected, acceptable AC input voltage range will be within 90~280VAC
UPS
If selected, acceptable AC input voltage range will be within 170~280VAC
Generator
If selected, acceptable AC input voltage range will be within 90~280VAC
