AC output/input data
Rated output/input power 6000/6000W
Rated output apparent power 6000VA
Nominal voltage 230 a.c.V
Rated input / output current
27/27 a.c.A
Nominal Frequency 50Hz
Power factor range 0.8leading~0.8lagging
Stand alone data
Rated output apparent power 4000VA
Nominal voltage 230 a.c.V
Rated output current 17.5 a.c.A
Nominal Frequency 50 Hz
Power factor range 0.8leading~0.8lagging
Battery data
Battery voltage range 42~59 d.c.V
Rated charging and
discharging current
85 d.c.A
Type of Battery Lithium/Lead-acid
other
Safety level Class I
Overvoltage category PV:II AC:III Others:I
Ingress protection IP65
Operation Ambient Temperature
-25℃~+60℃
Inverter topology Non-isolated
Certificate No SAAXXX

Other manuals for Growatt SPH Series

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Growatt SPH Series and is the answer not in the manual?

Growatt SPH Series Specifications

General IconGeneral
TypeHybrid Inverter
Max. Input Voltage600V
Number of MPPTs2
Protection RatingIP65
Output Power Range3kW - 10kW
Rated AC Output Power3-10 kW
Communication InterfacesRS485, USB, Wi-Fi
Output Voltage230 V
Frequency50/60 Hz
Operating Temperature-25°C to 60°C
Cooling MethodNatural Convection
